Product Details
Round tube motor
Smooth lines
Delicate appearance
High quality material
Resistance to wear and tear
Adapt to work environment with special needs
Parameters
|
Item
|
Specifications
|
|
Winding type
|
Star/Delta
|
|
Hall effect angle
|
120°
|
|
Shaft runout
|
0.025mm
|
|
Radial play
|
0.02mm/450g
|
|
End play
|
0.8mm/450g
|
|
Max radial force
|
28N/20mm from the flange
|
|
Max axial force
|
10N
|
|
Insulation class
|
Class B
|
|
IP class
|
IP 40
|
|
Dielectric strength
|
500VDC for one minute
|
|
Insulation resistance
|
100MΩmin 500VDC
|
|
Model NO.
|
Rated Voltage
|
Rated Current
|
Rated Power
|
Rated Torque
|
Peak Torque
|
Rated Speed
|
Length
|
Mass
|
|
42BLY40-140
|
12v
|
1.1A
|
10w
|
0.024nm
|
0.072nm
|
4000rpm
|
40mm
|
0.2kg
|
|
42BLY60-150
|
12v
|
1.6A
|
15w
|
0.029nm
|
0.087nm
|
5000rpm
|
60mm
|
0.3kg
|
|
42BLY80-150
|
12v
|
2.7A
|
25w
|
0.048nm
|
0.144nm
|
5000rpm
|
80mm
|
0.4kg
|
|
42BLY40-250
|
24v
|
1.1A
|
20w
|
0.038nm
|
0.114nm
|
5000rpm
|
40mm
|
0.2kg
|
|
42BLY60-260
|
24v
|
1.6A
|
30w
|
0.048nm
|
0.144nm
|
6000rpm
|
60mm
|
0.3kg
|
|
42BLY80-260
|
24v
|
3.3A
|
60w
|
0.096nm
|
0.288nm
|
6000rpm
|
80mm
|
0.4kg
|
Company Profile
Corporate Vision
To be the world’s business center of information in China which connects all SME’s, corporate entities and Individuals to enjoy the right service at a relative price in purchasing and supplying of innovative Industrial products.
Corporate Mission
To be the one stop solution center that builds value for our customers using the right kind of innovative means in our manufacturing process that result in building a well-designed products to fulfill the wants and needs of our customers at the right price that result in customer satisfaction.
Customer Feedback
Our customers for the past years doing business with us have been fun and exciting throughout. The trust-worthiness and consistency of doing business with Lunyee has been the blood stream for our growth and development. Our customers come from all over the world, be it in the SME’s sector, Corporate entities, Individuals and all new set up’s of businesses trust Lunyee.
Lunyee strive to develop long term customer relationships based on 24/7 parts & service support, continuous technology upgrades, and an extensive array of aftermarket programs that will foster a deep sense of business relationship in respect to emergency site service, equipment refurbishment, system audits, maintenance refresher training and others bearing in mind that our customers are the blood stream of the company.
Shipment & Delivery
FAQ
FAQ
1. Q: What's type of your company?
A: We are manufacturer.
A: We are manufacturer.
2. Q: what should I provide when I choose BLDC MOTOR?
A: 1) load condition
2) speed of rotation or speed ratio(combination with combine speed reducer can get extra low out putting rotational speed)
3) work circumstance(temperature, humidity,corrosion etc.)
4) space of installation
A: 1) load condition
2) speed of rotation or speed ratio(combination with combine speed reducer can get extra low out putting rotational speed)
3) work circumstance(temperature, humidity,corrosion etc.)
4) space of installation
3. Q: How long dose it take to finish my order?
A: It depends on your quantity.
A: It depends on your quantity.
