| Technical details | |
| Model | L Type Incline Conveyor |
| Machine frame | Fully stainless steel #304/Carbon Steel(Customized) |
| Chain | SUS304(Customized) |
| Bucket material | Food grade ABS, PP, SUS304,SS316 |
| Conveyor bucket | 1.8 L(Customized) |
| Voltage | 220V or AC380V |
| power | 750W |
| Speed | Max 90 buckets/min |
| Machine weight |
500-600 Kgs |
|
Packed dimension |
2100*850*1200 mm |
1.According to customer needs and different specifications made .
2.the elevator can complete the Material handling automatically.
It s suitable use in delivery the grain, food, food stuff etc.
Conveyor with the character of large quantity. NO crash material. High Lifting etc.
Lifting height:3.3-10m(according to customers requires)
It can be made both stainless steel and plastic painted .The contact parts of food grade plastic.
It can connect with different kinds of packing system to feeding materials into the system.
The height of this kinds of elevators can be adjust according to the requirement from customer,as some of them,the height of factory is lower than standard size.
Voltage:AC380V/220V/750W.
Boost speed:90 hoppers/min.
