Products Description
Rotary evaporator is an ideal instrument necessary for the concentration, drying and recycling relied on by the chemical industry, pharmaceutical industry, foods, environmental protection, universities and colleges, and research laboratories and so on.
|
Model
|
RE-52AA
|
RE-2000
|
RE-5000
|
RE-5210
|
|
Capacity
|
1L
|
2L
|
5L
|
10L
|
|
Rotating flask
|
0.5L ( 0.1L, 0.25L, 1L, 2L are optional)
|
2L + 1L (0.1L,0.25L,0.5L are optional)
|
5L ( 3L, 2L, 1L are optional)
|
10L / F95
|
|
Receiving flask
|
0.5L
|
1L
|
3L
|
5L, bottom discharge
|
|
Lifting type
|
Hand lifting / automatic lifting optional
|
Automatic lifting
|
Automatic lifting
|
Automatic lifting
|
|
Condenser
|
Vertical
|
Vertical
|
Vertical
|
0.57 m2 condensing surface
|
|
Rotation speed
|
0-150 rpm
|
20-200 rpm
|
0-110 rpm
|
3-100 rpm
|
|
Evaporation sped (H20)
|
1.2 L/H
|
1.2 L/H
|
2 L/H
|
3 L/H
|
|
Bath power
|
1100W
|
1500W
|
2200W
|
3000W
|
|
Static temp. control range & wave
|
RT-99±2 ℃
|
RT-99±2 ℃
|
RT-99 (150 ) ±0.2 ℃
|
RT-99 (150 ) ±0.2 ℃
|
|
Power
|
220V 50/60Hz
|
220V 50/60Hz
|
220V 50/60Hz
|
220V 50/60Hz
|
Working principle of rotary evaporator is under the vacuum condition, constant temperature heating, evaporation bottle be rotary by constant speed, material forming a large area film at the wall of bottle, efficient evaporation.Solvent vapors through the efficient glass condenser cooling, recycling in the collection bottle, improve the efficiency of evaporation.
Application
Rotary evaporator is mainly used in pharmaceutical, chemistry and bio-pharmaceuticals industries, for concentration, crystallization, drying, separation and solvent recovery. Especially suitable for the biological products concentration and purification which is easy to decompose deformation under high temperature.
