Products Description
FEATURES:
1. AC motor with step-less speed regulation or frequency converter, no brush, no spark
and long useful life.
2. Equipped with speed feedback system. Constant rotating speed, and won’t effected
by the change of material viscosity and voltage.
3. Digital display and controlled water/oil bath and heating mantle is option.
4. PTFE Stirrer(Anchor type, frame type, propeller type, four-blade type for choose)
Anti-corrosion, anti – adhesion, meet the requirements of various experiments.
5. We can provide customized service according your requirements.
Our Advantages
Product Paramenters
|
Model
|
S312-90
|
S312-120
|
S312-250
|
|||
|
Max. stir quantity (H2O)
|
2-5L
|
10-20L
|
20-50L
|
|||
|
Motor power
|
90W
|
120W
|
250W
|
|||
|
Voltage
|
AC 220V
|
AC 220V
|
AC 220V
|
|||
|
Speed range
|
0-1200rpm
|
0-1200rpm
|
0-1200rpm
|
|||
|
Display
|
LED
|
LED
|
LED
|
|||
|
Speed display resolution
|
±1rpm
|
±1rpm
|
±1rpm
|
|||
|
Torque
|
≤40N.cm
|
≤80N.cm
|
≤162N.cm
|
|||
|
Motorschutz
|
Auto-stop
|
|||||
|
Max. Viscosity
|
10000mPas
|
50000mPas
|
100000mPas
|
|||
|
Spindle adjustment range
|
1.0-10mm
|
1.0-10mm
|
1.5-13mm
|
|||
|
Size of base plate
|
330*350mm
|
330*430mm
|
350*450mm
|
|||
|
Environment temperature
|
5-40℃
|
5-40℃
|
5-40℃
|
|||
|
Relative humidity
|
80%
|
80%
|
80%
|
|||
|
Size(mm)
|
330*350*800
|
330*430*1000
|
350*450*1200
|
|||
|
The height can customize.
|
||||||
