Products Description
XTRAMIG-200 SYNERGY MULTI-FUNCTION IGBT INVERTER WELDING MACHINE
The latest DECAPOWER multi-function Synergy series microprocessor controlled inverter welding machine can satisfy your demands totally ! ALL IN ONE: GAS MIG/MAG welding, NO-GAS Flux cored wire welding, Braze MIG welding, Aluminium Wire welding, Copper Wire Welding, Stainless Steel wire welding, SPOTWelding, 2T/4T Welding, ARC Stick welding, DC lift TIG welding.
The quick SYNERGIC regulation of the welding parameters, makes this product easy to use. The intelligent and automatic control of the arc, moment by momment, maintains high welding performance in all working conditions, with different matrials and/or gases.The operator can also inervene manually along the arc length.
Details Images
Product Paramenters
Product Model:
|
XTRAMIG-200 SYN
|
||||||
Product Description:
|
IGBT INVERTER MIG-MAG/FLUX/TIG/MMA INVERTER WELDING MACHINE
|
||||||
Rated Input Voltage:
|
1phase, 230V +/- 15%
|
||||||
Rated input Power:
|
7.5Kw
|
||||||
Frequency:
|
50/60Hz
|
||||||
No-load Voltage:
|
60V
|
||||||
Rated Duty Cycle:
|
40%
|
||||||
Effenciency:
|
85%
|
||||||
Class of Insulation:
|
F
|
||||||
Protection Level:
|
IP21
|
||||||
Power Plug:
|
20A
|
||||||
Output Current:
|
MMA/ARC/STICK
|
20-200A
|
|||||
MIG/MAG/FLUX
|
20-200A
|
||||||
TIG/ LIFT TIG
|
20- 200A
|
||||||
Function Support:
|
HOT START
|
Available
|
|||||
ANTI STICK
|
Available
|
||||||
ARC FORCE
|
Available
|
||||||
FLUX WELDING
|
Available
|
||||||
PULSE WELDING
|
NOT Available
|
||||||
Size & Weight:
|
Product Dimension
|
570x280x450mm
|
|||||
Poduct Weight
|
14Kg
|
||||||
Package Dimension
|
620x320x480mm
|
||||||
Package Weight
|
18Kg
|
||||||
Accessories:
|
Standard Accessories:
|
– 1x MB15AK MIG TROCH with 3m cable
|
|||||
– 1x 200A Electrode Holder with 2m cable
|
|||||||
– 1x 300A Ground Clamp with 2m cable
|
|||||||
– 1x Welding mask
|
|||||||
– 1x Chipping Hammer/Brush
|
|||||||
– 1x Manul Book
|
|||||||
Optional Accessories:
|
– WP17V LIFT TIG Torch with 4m cable.
|
||||||
– Others
|
|||||||
*** NOTE: the optional accessories is required extra cost, if you need them, please inquiry factory before placing order ***
|
FAQ
The more relative products you may like.
Click bellow picture for getting more information!
Company Profile
Our Manufacturer
TAIZHOU LEMIN WELDING EQUIPMENT CO., LTD is the manufacturer of DECAPOWER company group.We’re focusing on developing and producing reliable quality Inverter Welding Machines and Air Plasma Cutter with favorable price, such as MMA/ARC WELDER, TIG WELDER, MIG WELDER and AIR PLASMA CUTTER which has been approved by CSA, CCC, CE certificate.
Core Target
Tailor client’s assortment products with innovation, competitive price and well presentation.
People
We’re culturally diverse globally gained. Our Knowledge and Industry focused terms are driven to satify and exceed customer’s
expectations.
expectations.
Culture
Our “CAN-DO” and “YES.WHY NOT” philosophy defines DECAPOWER’s global approach. Our customer-centric spirit makes it easy to work
and being partner with us.
and being partner with us.
Exhibition
Reviews
