Product Description
Specification
|
40m Fog Cannon Machine
|
||||
|
Dimension
|
1650*1000*1750 mm
|
|||
|
Impeller
|
Double impeller
|
Total 16 leaves
|
||
|
Motor Power
|
Fan motor
|
5.5kw
|
||
|
Water pump motor
|
3kw
|
|||
|
Water pump
|
Model
|
60 model
|
||
|
flow
|
40L /min
|
|||
|
Electric control box
|
shell
|
Thickened metal shell
|
||
|
Effective range
|
35-40m(No wind)
|
|||
|
operate
|
Manual, semi-automatic, fully automatic
|
|||
|
Water ring
|
Stainless steel material
|
16 nozzles
|
||
|
Pitch angle
|
0-60°
|
|||
|
Maximum rotation angle
|
320°
|
|||
|
Water tank capacity
|
200L
|
|||
|
Voltage
|
380v
|
|||
|
50m Fog Cannon Machine
|
||||
|
Dimension
|
1950*1200*2000 mm
|
|||
|
Impeller
|
Double impeller
|
Total 18 leaves
|
||
|
Motor Power
|
Fan motor
|
11kw
|
||
|
Water pump motor
|
5.5kw
|
|||
|
Water pump
|
Water pump
|
100 model
|
||
|
flow
|
80L /min
|
|||
|
Electric control box
|
shell
|
Thickened metal shell
|
||
|
Effective range
|
Effective range
|
|||
|
operate
|
Manual, semi-automatic, fully automatic
|
|||
|
Water ring
|
Stainless steel material
|
24 nozzles
|
||
|
Pitch angle
|
0-60 °
|
|||
|
Maximum rotation angle
|
320°
|
|||
|
Water tank capacity
|
600L
|
|||
|
Voltage
|
380v
|
|||
Product application range
Widely used in environmental protection
industry, city appearance and municipal administration, environmental sanitation bureau, environmental protection bureau,
gardening bureau, urban construction bureau, urban solid waste center, agriculture and forestry bureau, mine dust reduction,
garbage dump disinfection and deodorization, coal storage yard, coal port terminal, refinery Steel mills, stone processing plants
and other construction sites with relatively large dust. Large-scale sterilization, deodorization, epidemic prevention, etc. in
public places and after natural disasters
industry, city appearance and municipal administration, environmental sanitation bureau, environmental protection bureau,
gardening bureau, urban construction bureau, urban solid waste center, agriculture and forestry bureau, mine dust reduction,
garbage dump disinfection and deodorization, coal storage yard, coal port terminal, refinery Steel mills, stone processing plants
and other construction sites with relatively large dust. Large-scale sterilization, deodorization, epidemic prevention, etc. in
public places and after natural disasters
Main structure
Water tank, water pipe, plunger pump, nozzle,
fan, generator set (gasoline or diesel), horizontal steering device, vertical pitch device, electric control box, remote control,
etc.
The nozzle of the fog cannon is made of stainless steel. If the water quality is not good, it will be easier to break. We will
provide customers with a few more when shipping.
fan, generator set (gasoline or diesel), horizontal steering device, vertical pitch device, electric control box, remote control,
etc.
The nozzle of the fog cannon is made of stainless steel. If the water quality is not good, it will be easier to break. We will
provide customers with a few more when shipping.
