Tiger Rig Manufacturers 0.5ton 120m QJ0.5/120A Rope Pneumatic Air Winch for Workover Rig
Chengdu Zhonghang Machinery Co., Ltd( brand: tiger rig) was established in 2005 year, and reformed into a private enterprise in 1990.The company lies in Xindu town, Chengdu City, which is the most vigorous, and most potential city at the west of China. Tiger rig devoted itself to the research on the wellhead tools, and the great-leap-forward development. Drill pipe power tong designed and manufactured by the company is a necessary and symbolic tool for mechanized wellhead operation; a batch of automation wellhead tools represented by Iron roughneck developed in recent years creates the new era for drilling machines on the wellhead. The company is a specialization company with longest history, complete varieties, and strongest capacity for developing and researching wellhead tools and equipment. At present, the company has formed more than 50 series and more than 100 specs of products, which have been widely used in all oilfields in China, and have been export to Europe, America, Southeast Asia, the Middle East, Central Asia, North Africa and other regions.
QJ series of air winches are powered by piston-type air motor. They have the advantages of compact structure, light weight, safe and easy to operate and they are used for general lifting, hauling and other works in mines, oil fields, on shipboards and etc.
QJL0.5/40(A) |
QJ0.5/120(A) |
QJ1/100(A) |
QJ3/200(B) |
QJ5/120(B) |
QJ5/220(B) |
||
Air Pressure |
MPa |
0.5-0.9 |
|||||
psi |
72-130 |
||||||
Max. Pull |
kN |
5 |
5 |
10 |
30 |
50 |
50 |
Max. Line Speed |
m/min |
12 |
24 |
12 |
35 |
20 |
12 |
ft/min |
39.3 |
78.6 |
39.3 |
114.8 |
65.6 |
34.3 |
|
Wire Rope Diameter |
mm |
8 |
8 |
11 |
15.875 |
15.875 |
19 |
in |
5/16 |
5/16 |
7/16 |
5/8 |
5/8 |
3/4 |
|
Size |
mm |
495×365×380 |
675×343×460 |
825×343×450 |
1340×940×985 |
1300×940×985 |
1360×890×750 |
in |
19.5×14.3×15 |
26.5×13.5×18 |
32.5×13.5×18 |
53×37×39 |
51×37×39 |
53.5×35×29.5 |
|
Weight |
Kg |
45 |
117 |
162 |
600 |
580 |
800 |
lb |
100 |
258 |
357 |
1320 |
1280 |
1760 |
What buyers need to do?
1.Please provide the original brand, model and drawing number of accessories of the equipment you are using. If you do not know the specific name of the accessories of the wellhead equipment or tools, you can provide the pictures as the supporting evidence, and we will transfer them to the technology department for verification.
2.We will reply within 1 hour after receiving your inquiry for wellhead equipment or tools accessories, and offer you in the next day.
