Tiger Rig Long Life HDP HDS Drilling Pipe Kelly Spinners A6C Type for Skid Mounted Drilling Rig
Chengdu Zhonghang Machinery Co., Ltd( brand: tiger rig) was established in 2005 year, and reformed into a private enterprise in 1990.The company lies in Xindu town, Chengdu City, which is the most vigorous, and most potential city at the west of China. Tiger rig devoted itself to the research on the wellhead tools, and the great-leap-forward development. Drill pipe power tong designed and manufactured by the company is a necessary and symbolic tool for mechanized wellhead operation; a batch of automation wellhead tools represented by Iron roughneck developed in recent years creates the new era for drilling machines on the wellhead. The company is a specialization company with longest history, complete varieties, and strongest capacity for developing and researching wellhead tools and equipment. At present, the company has formed more than 50 series and more than 100 specs of products, which have been widely used in all oilfields in China, and have been export to Europe, America, Southeast Asia, the Middle East, Central Asia, North Africa and other regions.
We can supply wellhead product as such drilling pipe power tong, casing power tong, hydraulic power tong, air winch, hydraulic cathead, rotary cathead, casing guide, deadline anchor, Kelly bushing, master bushing, Kelly or swivel spinner, casing tubing coupling bucking unit, Elevator, Spinners, slip ,clamp and so on.
Our company owns reliable quality administration system, and has obtained ISO9001,ISC14001, GB/T28001, GOST and API Q1 certificates. Our products have been grant the right to use the Official Monogram of API Spec 7K and API Spec 8C.
Adhering to the “people-oriented, technology leadership, honest and quality excellent, win-win cooperation, the customer first” business idea, and carefully creating “tiger rig” brands. Firmly aimed at the international advanced technology and management philosophy for petroleum machinery. We will make our efforts to supply the best surface operation tools and the drilling and producing equipment for the oilfields in China and the world.
We are primary supplier of CNPC (china national petroleum company).
We can guarantee the successful delivery time for your overseas bidding projects, and guarantee the purchase of China’s first-class oil equipment, and make sure your end user are satisfied with our wellhead equipment and tools.
If you need to buy a wellhead tool with stable quality and more than 20 years of history, please feel free to contact us.
Kelly spinner is a special equipment to connect single pipe by matching with mouse hole clamping device. It unitizes air or hydraulic motor to drive Kelly to rotate and it has the features of security, labor-saving and high efficiency. It is designed and manufactured according to API Spec 8C “Specification for Drilling and well Equipment”.
Model |
FXD |
QF2 |
Q3 |
A6C |
6600 |
|
Drive mode |
Pneumatic Driven |
|||||
Max. static load |
kN |
2250 |
||||
US ton |
250 |
|||||
Pressure |
Mpa |
0.5-0.9 |
||||
psi |
72-130 |
|||||
Brake torque |
N.m |
1200 |
1600 |
1650 |
1500 |
1500 |
ft.lbf |
885 |
1180 |
1215 |
1100 |
1100 |
|
Idle speed |
rpm |
76 |
72 |
72 |
170 |
130 |
Rotary direction |
Single |
Double |
||||
Stem connection |
6-5/8 REG LH |
|||||
Size |
mm |
845*740*725 |
558*558*935 |
860*725*980 |
768*768*1225 |
740*710*978 |
in |
33*29*28 |
22*22*37 |
34*28*39 |
30*30*48 |
29*28*38.5 |
|
Weight |
kg |
383 |
450 |
520 |
540 |
500 |
lb |
844 |
992 |
1146 |
1190 |
1100 |
What buyers need to do?
1.Please provide the original brand, model and drawing number of accessories of the equipment you are using. If you do not know the specific name of the accessories of the wellhead equipment or tools, you can provide the pictures as the supporting evidence, and we will transfer them to the technology department for verification.
2.We will reply within 1 hour after receiving your inquiry for wellhead equipment or tools accessories, and offer you in the next day.
3.Please provide office word format, Not JPG pictures. We need to translate them into
Chinese. If it is JPG format, the quotation time will be extend by 1-2 days. Try to provide
the original bidding document as a reference. If there is any doubt, we will mark it to
facilitate you to check the name and size of the real wellhead tools accessories.
4.If you need accurate weight and size, please indicate them in the mail together, and we will provide CIF price to facilitate your freight calculation.
5.For wellhead equipment accessories, we provide export fumigation free wood packaging, and the cylinder liner is frame packaging. If you need iron box packaging, please inform in advance.
About the seller: what should we do?
1.Before signing the contract, we have determined the product pictures. Once the customized products are confirm, they cannot be return.
2.Before prepaying 70% of the final payment, we provide the pictures of the official goods. Please check carefully, compare the physical objects and parameters repeatedly, or send them to the end user for confirmation, to avoid wrong delivery. If the wellhead tools or parts are not inspected, wrong delivery of bop parts, and reissue, we need to place another new order. Wellhead equipment parts are conventional products, please give us the parts number, if u book rubber, we can provide the drawings for verification. After the review and confirmation, we will Seal case to Shanghai port.
3.A large number of spare parts of all drilling wellhead equipment and drilling wellhead tools are in stock, with a stock of 200 million yuan. All of them are supplied by CNPC (China national Petro Company) products in the stock. When the world orders, they can be send out the next day to support Alibaba online direct orders.
4.The warranty period of rubber parts is one year. Please open the box for use as soon as possible within one year. Other iron accessories can be stored for 2-3 years, but we suggest you use them as soon as possible. The warranty period is one year.
5.If wellhead equipment parts are misbelieved or missed due to our company’s reasons, our company will provide free replenishment or replacement, please feel free to purchase.
Check if there is an agent in your location. If there is, we will let our agent contact you to facilitate your after-sales service.
1.We will reply to your inquiry within two hours after receiving it, and arrange a special person to contact you. Please leave WhatsApp, WeChat and other communication tools as far as possible, so as to find yourself easily. If there is no response, please send a second letter.
2.Our company has a professional technical team and professional translators (Spanish, Arabic, Russian, and English). If you need to communicate with Russian service personnel, please inform them in advance by email.
3.We will provide the most competitive price in the Chinese market according to the requirements of your bidding documents to ensure the successful completion of your bidding project, so please give us sufficient preparation time, preferably the latest bid closing date.
