Request quotation for: Tensile strength testing machine/universal tensile tester/tensile tester

Product Description

Equipment summary:

The machine is designed by mechanical-electrical integration, composition of the force-measuring sensor, transmitter,microprocessor, mechanism of load drive, computer and color inkjet printer. High-precision electronic motor can be set to five-speed, the components are connected by plug-way, Floor-standing models, it is taken account of modern industrial design and ergonomics in modeling and coating. It can be tested all the materials in stretch, compression, bending, shear, embedded relay, peeling, tearing, crack, etc,such as rubber, plastics, leather, metal, nylon wire, fabric, paper, aerospace, packaging,construction, petrochemical, electrical, vehicle, etc.

APPLICATIONS

Microcomputer-controlled electronic universal testing machine is a high-precision, multi-purpose material testing machine that tests the mechanical properties of various metal materials, non-metal materials, composite materials, and polymer materials in the state of tension, compression, bending, shearing, peeling and tearing.
Specification
item
value
Warranty
1yaer
Certification
CE
Customized support
OEM, ODM, OBM
Place of Origin
China
Brand Name
YUYANG
Model Number
YYL056
Power
Electronic
Maximum load
1Ton
Force unit
N,KN,Kgf,Lbf
Power consumption
0.5 kVA
Power source
220 VAC, 50/60 Hz
Volume
760x60x210cm
Weight
200kg
Effective width of test
380 mm
Test stroke (including fixture)
800 mm
Speed control accuracy
±0.2% (0.5 Grade )
control mode
Computer software sets speed, sets load breaking (breaking), running

time and other control methods
Manual operation box
It is convenient to calibrate and position the specimens when loading and

 holding them. It can automatically determine the material breaking,
crushing, and stop the machine. It can be set to return
 automatically
Curve type
 Load – displacement, load – time, displacement – time.
Stress – strain, strain – time, stress – time.
Curve vertical and horizontal coordinates can be set arbitrarily.
Available test data
Maximum strength, minimum strength, fracture value, upper and lower
yield strength, tensile strength, compressive strength,

modulus of elasticity, elongation, maximum, minimum, mean value, etc.

It has multiple protection such as overload, overcurrent,
overvoltage, undervoltage, overspeed and travel.
Load sensing
High precision pressure and tension actuator,(multiple sensors can be

installed at the same time – optional)
Test speed range
servo-type: 0.5~500 mm/min Speed Promise
