Product Application
Concrete pump is a kind of composite pumping requirements of concrete pump, through the horizontal or vertical installation of pipelines, the scene of the continuous conveying to the pouring fine stone concrete conveying equipment, widely used in the second post filling, floor heating engineering, roofing, wall of high-rise building, reservoir and hydropower station, port, wharf, basic processing soft foundation reinforcement grouting subway tunnel backfill grouting bolt support in mine construction.
The device is small and easy to move, and it doesn’t have to be afraid of pebbles. It can accommodate 2.5 CM of stones, easy to pour and 7.1 square hours of an hour.
|
Concrete pump QJ-W-9B
|
||||||
|
model
|
QJ-W-9B
|
Overall dimensions
|
1900*700*1150
|
|||
|
The motor power
|
15KW
|
Work form
|
S pipe valve type
|
|||
|
Feeding height
|
0.5m
|
Vertical conveying distance
|
10-25M
|
|||
|
Horizontal conveying distance
|
10-60M
|
The maximum aggregate size
|
3CM
|
|||
|
The theoretical maximum throughput
|
7.1cubic/h
|
Maximum pressure; Pressure of work
|
15Mpa;5Mpa
|
|||
|
Pipe diameter
|
80MM
|
Machine weight
|
490KG
|
|||
Main Features
(1) the use of the pump power is Very powerful,
(2) is a small volume of concrete pump, is the ideal choice for many narrow construction environment.
(3) the pump light weight, mobile convenience.
(4) pump configuration is high, the hydraulic operation, stable performance, compact structure, low fault rate and long service life.
5;Two control modes, which can be controlled remotely by remote control, and can be controlled manually.
6. Lift hopper, when the hopper rises when moving, the hopper is placed on the ground, and the car can be directly dumped into the bucket.
7. Infinitely variable speed, the flow of concrete can be adjusted freely, 1m3 / h – 7m3 / h.
8. Multiple protection functions of the imported electronic control system: prevent the lack of phase, prevent leakage, prevent reverse, and do not burn the motor.
9. Positive pump: pump concrete;
Backpump: the concrete in the back of the tube.
Second post casting special pk traditional infusion pump construction process:
1,The device is small and easy to move, and it doesn’t have to be afraid of pebbles. It can accommodate 2.5 CM of stones, easy to pour and 7.1 square hours of an hour.
2, constructional column construction equipment one operator can start, but traditional perfusion construction working strength is big, therefore always faced with lack of engineering construction, recruitment difficulties and other issues.
Good quality, good service, to upgrade become a kind of enjoyment
Machine
Name: concrete pump
Brand: QIJI
Original: CHINA
Qiji-w-9 micro-pouring pump adopts hydraulic principle, low failure rate and high efficiency;
Can transport mortar, mortar, concrete with fine stones, secondary post grouting materials such as material, this device power is strong, can be up to 25 m vertical conveying capacity and level of up to 60 m, solve the problem of the secondary structure of casting, pumping system is several times of artificial construction
Pre-Sales Service
* WhatsAPP;+8613703194661.18732920203
* Wechat;fanminga.
* QQ;402670646
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|
Packaging
|
||
|
Size
|
2000 (L) *750 (W) *1200 (D)
|
|
|
Weight
|
0.52T
|
|
|
Packaging Details
|
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
|
|
