Brief introduction:
ZP-5/7/9B rotary tablet press (enhanced type) is a single pressure automatic rotation, continuous compression machine, the raw material into a variety of tablets. It is mainly used in the production of pharmaceutical tablets, while suitable for chemical, food, electronics and other industrial sectors. The periphery of the shell is completely closed, the material is made of stainless steel, the stainless steel material is used in the inner surface, and the surface of the turntable is specially treated to keep the surface gloss and prevent cross contamination, which is in accordance with the requirements of GMP. With transparent glass doors and windows, can clearly observe the state of the tablet, and can all open, easy to clean and maintain internal. All controllers and operating parts are well distributed. The frequency conversion speed regulating device is adopted for the electric speed regulation, the operation is convenient, the rotation is stable, and the safety is accurate. All drives are arranged inside the machine to keep the machine clean. Equipped with overload protection device, when the pressure overload, can automatically stop. This machine is equipped with electromagnetic brake motor and other safety protection devices.
Main Features:
1.Pressure is up to 60KN, strong stability, the fuselage is mainly made of stainless steel and aluminum alloy, making the fuselage more portable.
2.Humanized knurling screwoperating table, more convenient to operate.
3.Stainless steel material, is in line with GMP production requirements.
4.Stainless steel shield can prevent raw materials from entering turntable and damage equipment.
5.Aluminum alloy sheet turbine boxmakesthe fuselage lighter.
6.The magnetic sliding door is used on all sides of the turbine chamber of the motor, which is convenient for inspection and maintenance.
7.High quality aluminium alloy wheels, easy to move.
Technical parameters:
Scope of Application
1) This is a compact type of the automatic rotation and continuous tablet press, mainly used in the technical research in pharmaceutical, chemical, food, electronic and other industries, and it is an important equipment for determining whether the grain materials can be pressed into tablets.
2) It is applicable to pressing of grain materials available to be made into tablets (within the range of pressure of the machine) with the powder content (above 100 mesh) not more than 10%.
3) It is applicable to pressing of regular/irregular shape and scoring tablets.
4) It is not applicable to semi-solid, wet grain, materials of low melting point and easily absorbing dampness and powder without grain.
