Shape features |
stainless steel casing/black aluminum shell and color touch screen |
|
Dimension |
140*80*235mm |
|
Net weight |
0.996kg |
|
Printing direction |
adjusted within 360 degree, meet all kinds of production needs |
|
Character type |
high-definition printing character, dot matrix font, Simplified, Traditional Chinese and English |
|
Printing pictures |
all kinds of logo, pictures can be uploaded through USB disk |
|
Printing accuracy |
300-600DPI |
|
Printing line |
1-8 lines (adjustable) |
|
Printing height |
1.2mm-25.4mm |
|
Print code |
bar code, QR Code |
|
Printing distance |
1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm) |
|
Print serial number |
1~9 |
|
Automatic print |
date, time, batch number shift and serial number, etc |
|
Storage |
the system can store more than 1000 mass (external USB make the information transfer in a free way) |
|
Message length |
2000characters for each message, no limitation on length |
|
Printing speed |
60m/min |
|
Ink type |
Quick-dry environmental ink, water-based ink and oily ink |
|
Ink color |
black, white, red, blue, yellow, green, invisible |
|
Ink volume |
42ml(usually can print 800,000 characters) |
|
External interface |
USB, DB9, DB15, Photoelectric interface, can directly insert a USB disk to upload information |
|
Voltage |
DC14.8 lithium battery, print continuously more than 10 hours and 20 hours standby |
|
Control panel |
touch-screen (can connect wireless mouse, can also edit information through the computer) |
|
Power consumption |
the average power consumption is lower than 5W |
|
Working environment |
Temperature:0 – 40 degree; Humidity: 10% – 80% |
|
Printing material |
board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum foil, etc. |
Q1. Can this printer print my product?
A: We have water-based ink cartridge and quick dry ink cartridge to suit different materials. Most of the products can be printed with EXP date, batch code, bar code, QR code, serial number, logo and other printing information.
Q2. Can the mark be erased?
A: No, if you do not scrape with hard tool, it can not be erased.
Q3. How long will it take for the ink to become dry?
A: 3-5 seconds.
Q4. How can I know your machine works well?
A: Before delivery, we have tested every machine and adjusted it to the best condition. If you have special production condition, we could also adjust the machine for you.
Q5.Can you ship the machine to my address?
A:Yes, we could use DHL to express the machine. While transport cost will be higher. Also, it is suitable for the small models.
Q6. Where are you? Can we go to China and visit your factory?
A:Yes, of course. We are in Hangzhou,China. Welcome to our factory.
Q7:Do you have manual with the machine?
A:Yes, of course. It is in English version.
Q8:Do you have other color inks?
A: Yes, We have white, yellow, red, green, blue, black these color for you choice.
