Main feature:
1. Core drilling rig with hydraulic automatic feed mechanism, improve drilling efficiency and reduce labor intensity.
2. The ball clamp clamping mechanism is used instead of the chuck, which can realize non-stop inverting of the rod, convenient operation, safe and stable.
3. Hydraulic core drilling rig equipped with a pressure gauge at the bottom of the hole for easy control of the situation in the hole.
4. Compact structure, centralized handle, small footprint, light weight, strong decomposability (reassemble at the construction site), and easy to move. Suitable for plain or mountainous operations.
| Model | HZ-130Y/130YY | HZ-180Y/180YY | HZ-200Y/200YY |
| Drilling depth (m) | 130 | 180 | 200 |
| Hole diameter (mm) | 220 | 220 | 325 |
| Final hole diameter (mm) | 75 | 75 | 75 |
| Drill rod diameter (mm) | 42-60 | 42-60 | 42-60 |
| Drilling angle (°) | 90-75 | 90-75 | 90-75 |
| Supporting power (kw) | 13.2 | 13.2 | 14.7 |
| Weight (kg) | 920 | 955 | 1150 |
| Size (mm) | 2400*950*1400 | 2400*950*1400 | 2700*950*1770 |
1. Q: Are you trading company or manufacturer?
A: We are original equipment manufacturer.
2. Q: How long is your delivery time?
A: It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
3. Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer you the sample machine.
But it’s not free. You need to pay for the sample and the cost of freight.
4. Q: What is your terms of payment?
A: We accept T/T, Western Union, Money Gram, Paypal, Escrow etc.
Payment<=USD 5000, 100% in advance.
Payment>=USD 5000, 30% T/T in advance, balance before shipment.
