Products Description
The advantages of CO2 RF tube marking machines mainly include the following aspects: 1. Low voltage operation: RF waves can complete high-frequency fluctuation modulation, the modulation frequency can reach 100kHz, the output optical power has a high degree of electronic control, and can flexibly realize the conversion from continuous to pulse and the adjustment of pulse width and pulse frequency. 2. Long life and high reliability: The life of CO2 RF tube marking machines is long, usually reaching more than 20,000-30,000 hours, with good beam quality, stable light output and low failure rate. 3. Wide range of applications: CO2 laser marking machines are suitable for a variety of materials and industries, such as non-metallic materials, organic materials, etc., and are widely used in automotive parts, electronic components, plastic products, packaging materials and other industries. 4. High-precision and detailed marking effect: CO2 laser marking machines can achieve high-quality marking effects on a variety of materials, such as plastics, glass, wood, rubber, etc., and are particularly suitable for use in food, medicine, wine, electronic components and other fields.
Machine parameters
|
Laser power
|
30w 40w 50w
|
||||||
|
Working area
|
100*100mm/150*150mm/200*200mm(Different machine working areas can be customized.)
|
||||||
|
Laser Wavelength
|
10.6um
|
||||||
|
Response time
|
0.5ms
|
||||||
|
Frequency of pulse
|
20-100KHz
|
||||||
|
Max marking depth
|
≤1.0mm
|
||||||
|
Marking lines
|
1-10 lines(in the marking area)
|
||||||
|
Minimum line width
|
0.015mm
|
||||||
|
Minimum character
|
0.15mm
|
||||||
|
Repeatability accuracy
|
±0.002mm
|
||||||
|
Resolution ratio
|
0.1mm
|
||||||
|
Marking content
|
Text,pattern,date,barcode,etc
|
||||||
|
Supply Voltage
|
110V/60HZ 220V/50HZ
|
||||||
Machine application
CO2 laser marking machine is currently a laser product with a high continuous output power. It is widely used in the field of non-metallic material cutting, and is used in leather, stone, jade, textile, medical, material processing, industrial manufacturing and other fields, especially in Industries such as logo marking and inkjet printing have unique applications.
Machine optional accessories
Rotary Device
Its main function is to help you engrave round objects.
Autofocus system
—
It can automatically find the focus of marking, saving you work time.
It can automatically find the focus of marking, saving you work time.
