Electrical Specifications: (23C5C)
mA DC Current: (1K Max. Load, 24V Loop Supply)
|
Range |
Resolution |
Accuracy |
|
0 4mA |
1A |
0.025% 10A |
|
4 20mA |
1A |
0.025% 5A |
|
20 24mA |
1A |
0.025% 5A |
Beeper warning when output is open and specified output > 1mA
V DC Voltage
|
Range |
Resolution |
Accuracy |
|
0 4V |
1mV |
0.05% 10mV |
|
4 20V |
1mV |
0.05% 5 mV |
|
20 24V |
1mV |
0.05% 5 mV |
Beeper warning when output is short and specified output > 100mV
General Specifications:
|
Dimension: |
88 x 168 x 26 mm (3.46" x 6.61" x 1.03") |
|
|
Battery Type: |
9V Alkaline Battery |
|
|
Display: |
4+ 5 Digits |
|
|
Power Consumption: |
25 mA at 100 load |
|
|
Operating Temperature: |
0C to 50C (32F to 122F) |
|
|
Operating Humidity: |
less than 85% relative |
|
|
Storage Temperature: |
-20C to 60C (-4F to 140F) |
|
|
Storage Humidity: |
less than 85% relative |
|
|
Weight: |
330g / 11.63 oz |
|
|
Accessories: |
|
Notes:the batteries not included in package
