HH-NL130 Automatic Aluminum Channel Letter Bending Machine
Technical Parameters
|
Working Principle
|
High Accuracy Automatic Feeding, Automatic Cutting, Automatic Bending
|
|
Model
|
HH-NL130 Aluminum Letter Bending Machine
|
|
Application Materials |
Flat Aluminum Coils, Rectangle/Triangle aluminum Coils,Aluminum Profiles, Channelume, Aluminum Coils with Foam and PC, High Polymer Coils for channel letter
|
|
Slot Degree
|
45-135 Degree(no limit for flat materials)
|
|
Bending radius
|
≥3.5mm
|
|
Material Width
|
≤130mm
|
|
Material Thickness
|
0.3-1.2mm
|
|
Total Power
|
1000W
|
|
File format
|
dxf, ai,plt
|
|
Machine size
|
2000*900*1550mm
|
|
Weight
|
300KG
|
|
voltage
|
220V
|
|
Air pressure
|
0.3-0.8Mpa
|
Main Features
1. Five-axis:
Feeding, lifting, cutting, and bending one-time forming to ensure accurate and stable cutting and bending .
2. With the closed loop self-test system, the whole deviation is less than 0.1mm.
3. Imported square rails for positioning cutting to ensure the cutting stability
4. The intelligent Rebound coefficient compensation to ensure the letter forming accuracy.
5. One-button operation, very easy to use. Cost-effective, stable cutting, low noises
6.Self-innovated Software, easy operation.
7. Automatic adjustment of cutting depth, convinient,fast,high efficient and stable
8. Simple Machine Test and Operation
9. High cost performance ratio
10. Special for high quality Aluminum Letters making
Application Industry
Applicable samples such as Rimless Letters,Aluminum Edge Letters,Resin Luminous Letters,Super Letters(Liquid Acrylic Letters),Aluminum Profile Letters,Aluminum Letters with Sponge, High Polymer Luminous Letters,Side Luminous Letters,LED Words and Various Aluminum Luminous Letters
Applicable materials such as aluminum coil
Package& Delivery
Packaging:Plywood with exporting standard
Delivery:About 7 days after receving the deposite
Delivery:About 7 days after receving the deposite
Service&Traning
we can provide 3 ways for Installation and training:
The first way: you can come to our factory for training.we will offer professional guide. Direct and effective face-to-face training.
The second way: our engineer will do a door-to-door instruction training service at your local site. but buyer is responsible for
our engineer 's round trip ticket, visa fee , hotel , food, training fee etc
The third way: we also can teach u how to operate and install by whatsapp, video , email etc.
The first way: you can come to our factory for training.we will offer professional guide. Direct and effective face-to-face training.
The second way: our engineer will do a door-to-door instruction training service at your local site. but buyer is responsible for
our engineer 's round trip ticket, visa fee , hotel , food, training fee etc
The third way: we also can teach u how to operate and install by whatsapp, video , email etc.
We will ensure our machines running well in customers
Certifcate&factory
Exhibitions Dispaly
FAQ
Q: Are you a factory or a trade company?
A: We are a factory.
A: We are a factory.
Q:Where is your factory?
A:Our factory located in Weifang city,Shandong Province,China.Warmly welcome to visit our factory!
Q: Warranty?
A: Depend on the series of machine.
A:Our factory located in Weifang city,Shandong Province,China.Warmly welcome to visit our factory!
Q.What's your payment terms?
A: Payment term is 30% TT as deposit,70% balance should be paid before shipping.
Q.Your delivery time is?
A:10-15 working days after deposit.
Q: Warranty?
A: Depend on the series of machine.
Q: Do you have patents or core technology?
A: Yes, for details, please contact our sales.
