Product Description

powder frequency spark tester, spark tester tool, 2021 Hot Sina wave High frequency wire and cable default testing Spark tester

Description:
Working conditions:

Model: GS-15S
Power supply: AC200-240V 50/60HZ
Ambient temperature: -5°C-50°C
Relative humidity: 20%-85%
Power consumption: ≤150W
Note: The spark machine should be grounded reliably

Technical index:
Output voltage: 0-15KV (effective value sine wave)
Voltage display: 3-digit digital tube display 0.0-15.0KV, voltage adjustment step length 100V
Defect times display: 5-digit digital tube display
Test wire diameter: MAX25mm
Test frequency: 2500-3500HZ, varies with the equivalent load capacitance
Electrode form: bead chain type, in line with UL1581 standard
Electrode length: 50mm
Test mode: manual automatic
Automatic leak detection recovery time: less than 20ms
Sensitivity: set to 3KV, use breakdown equipment to breakdown 20 times, no more than no more notes, breakdown current is not more than 600µA
Output current: 4mA resistive, 40mA capacitive
Allowable maximum linear speed: 3067m/min, in line with BS5099 and CCC standards
1000m/min, in line with UL1581 and CSA standards
Output contact: 250V 2A
Serial communication: RS-232 RS-422 optional
Maximum communication distance: 300m
Electrode cover safety interlock switch protection device


The high-frequency spark tester is a professional insulation leakage tester, suitable for online insulation testing in the wire and cable industry. It can detect pinholes, air gaps, cracks and other defects in the insulation coating on the surface of the wire and cable. Equipped with defect record and sound and light alarm system. When a defect is found, it will automatically record the defect data and generate an audible and visual alarm. You can also touch the relay to control the external alarm system, and send the defect record data to the PLC or PC workstation in time through the RS-232/422/485 full-duplex serial port for online control.
The breakdown sensitivity
Maximum moving speed of the examined line
Power supply voltage
Power supply frequency
Input power
1 ≤ 600 × 50 U. T ≤ 0.005s
1000 / m / min
AC220V+15%
50+2Hz
50VA
Ambient temperature
Relative humidity
Detect outer diameter
Dimension
Weight(KG)
-10 ≤ 45C
less than 85
Φ5/Φ10/Φ15/Φ20/Φ25
315*305*245(without bracket/package)
20
Related Model
Detection voltage
Detect outer diameter
Line ground center height(adjustable)
Electrode size
QP-15A
0~15KV
Φ1.0~20mm
850-1050mm
30*120mm
QP-25A
0~25KV
Φ2.0~50mm
850-1050mm
30*120mm
QP-15AC
0~15KV
Φ1.0~20mm
850-1050mm
30*120mm
Packaging & Shipping

Package:

will put in the box with * Shockproof membrane. do not worry the machine will be broken.

Weight and size

Weight about 27kg with package. , size 595*312*245mm. 0.05CBM. you can choose ship by air ..
Company Profie
FAQ

Q1: Are you a factory or trading company?
We are a factory . We can promise you a short lead time and best price if you purchase our machine. We also have our own trading department.

Q2: How does the factory ensure products quality?
With Nearly 16 years experience in manufacturing winding machine, we have our own technology develop department and testing department.
Quality is the first priority. We have strict purchasing system to ensure the quality of spare parts. We have experienced workers to assemble and test machine.

Q3:How about your after-sale service?
We have a professional technology supporting team for your timely services. You can get the help you need in time by telephone,webcam, online chat (Google talk, Facebook, Skype). Please contact us once the machine has any problem. Best service will be offered.

Q4: What are your payment terms?
100%TT or prepaid 50% , balance 50% before shipping.

Q5: How can I get my order? How can I know you sent the goods?
We will send the goods by UPS, DHL, FedEx or sea shipment. After we sent the goods, we will give you the tracking number or other relative files for checking.

Q6 : Will you send the installed machine or machine parts?
We will install the machine and test the machine before delivery. And the machine can be used directly after receiving the machine.

Q7: Will you provide operation guidance for us?
We will send the instruction book with the machine and send you a video about how to operate the machine.

Q8 : How long is the warranty period?
12 months warranty, we will send you free spare parts by air within one week if there are any quality problems.

Usage

Dc spark machine, Power frequency spark machine, High frequency spark machine
