Product Parameters
|
Model
|
Power model: LM20/LM25/LM30/LM50 |
Lithium battery model: LMB20/LMB25/LMB50
|
|
|
Machine material
|
Environmentally friendly engineering plastics
|
||
|
Laser Type
|
Fiber Laser Generator
|
||
|
Frequency adjustable range
|
1-600 khz
|
||
|
Laser output power
|
20W/25W/30W/50W
|
||
|
Power consumption of the whole machine
|
≤500W
|
||
|
Maximum power consumption W
|
20W: 250W / 30W: 280W
|
||
|
Power supply
|
AC 220V/110V, 50/60Hz
|
||
|
Battery life
|
6-8 hours
|
||
|
Continuous working time with full power
|
3.5-5.5 hours
|
||
|
Printing type
|
QR code, barcode, Chinese, English, numbers, logos, patterns, etc.
|
||
|
Laser wavelength
|
1064nm
|
||
|
Marking range
|
50mm*50mm, 100mm*100mm (standard), 150mm*150mm
|
||
|
Printing Orientation
|
Unidirectional Printing
|
||
|
Printing speed
|
≤7000mm/s
|
||
|
Font
|
Chinese, English, Korean, Russian, Japanese, Arabic numerals, etc
|
||
|
Positioning method
|
red light positioning
|
||
|
File format
|
JPG/PNG/BMP/DXF/SVG/PLT
|
||
|
Applicable industries
|
Metal, rubber, ceramic tiles, stone, wood, packaging ,etc
|
||
|
Weight
|
6.2KG
|
7.8KG
|
|
|
Dimensions
|
280mm*220mm*330mm (length, width and height)
|
||
|
Marking depth
|
0.2-1.2mm
|
||
|
After-sales service
|
Machine :1 year/power board and laser:2 years
|
||
