Product description
This durable and affordable solid content detector benefits from rich experience in precision instrument development, design, and manufacturing, as well as years of solid content determination expertise. The solid content detector is equipped with a high-precision imported weighing sensor and a high-efficiency imported halogen lamp heating device on the basis of a professional precision electronic balance to achieve fast and accurate solid content determination. The ring-shaped quartz tungsten halogen infrared heating source can dry samples quickly; compared with the international oven heating method, the ring-shaped quartz tungsten halogen infrared heating can uniformly and quickly dry the sample at high temperatures, and the sample surface is not easily damaged. The test results are comparable to the national standard oven method. Good consistency, replaceability, and the detection efficiency is much higher than the oven method, intelligent operation, the general sample only takes a few minutes to complete the measurement.
Applicable industries: widely used in industries such as silt, mud, paint, glue, slurry, admixtures, etc., to determine the solid content of samples in the laboratory and during the production process.
Product advantages:
(1) Instead of the national standard oven method, it has a wide range of uses and is suitable for the determination of solid content in various industries
(2) Precise electromagnetic force sensor, high measurement accuracy, long service life and stable performance
(3) One-key operation and graphical user guidance, even untrained operators are equally competent
(4) The high-efficiency heating system and temperature control system can determine the solid content of the sample within a few minutes, thereby ensuring a fast response time for quality control and process control
(5) The heating chamber adopts pure stainless steel chamber cover, which is strong and durable and easy to clean
(6 The unique windshield design makes the weighing system of the instrument more stable
(7) LCD display screen, rich data display (graph, time, real-time temperature, solid content, program module) Technical solution of precision instrument testing equipment
(8) No need to manually record the results, support standard print output, RS232 serial port, expandable computer communication, printer communication, PLC and network management
The main technical parameters:
|
Model |
ST-G1 |
|
Range (g) |
120-0.005 |
|
Readability |
0.01% |
|
Measurement result display mode |
Solid content DC% Total sample weight g Sample dry weight g Temperature ℃ Time Trend curve |
|
Operating temperature requirements |
Room temperature |
|
Calibration method |
External weight calibration |
|
Pan size (mm) |
Φ 90 |
|
Power-on warm-up (minutes) |
20-30 |
|
Baud rate |
9600 |
|
Monitor |
LCD liquid crystal display |
|
Heating temperature range (℃) |
RT~~200 |
|
Drying program |
(Standard heating, rapid heating method) Weightless heating mode |
|
Stop mode |
Automatic shutdown, manual shutdown, scheduled shutdown |
|
Set time |
0~99 minutes in 1 minute intervals |
|
|
Standard RS232 communication interface, printer, PC and other peripheral equipment can be connected |
|
Dimensions (length * width * height) (mm) |
310*205*200 |
|
Net weight |
4.5kg |
