CE,FCC Certification!Two Years Warranty!
Original Factory Alcohol Density Meter , Alcohol Densitometer, Alcohol Hydrometer
——High-precision,Multi-function,Digital disply,Accurate testing
Standards:In accordance with Archimedes principle, GB/T 611,GB/T1154,GB/T12206,GB/T5518 standards etc.
Adopt the dynamic measurement without memory;No need to press the button; Memory quickly;Automatically judge whether density is qualified or not and prompt alarm through the setting of top and bottom limitation; Function of measuring density with three mode; Get out of the cumbersome operation of re-calibrate when change weight; It is more high-precision, convenient, rapid,hommization; Function of displaying concentration ,density and baume.
Specification:
Model:DA-300W
Density resolution: 0.001 g/cm3
Maximum weight:300g
Minimum weight:0.005g
Measuring range: 0.001-99.999g/cm3
Model:DE-120W
Density resolution: 0.0001 g/cm3
Maximum weight:120g
Minimum weight:0.001g
Measuring range: 0.0001-99.9999g/cm3
Features :
(1)Density value can be showed by one procedure;repeated continuous rapid measurement can be worked.
(2)Digital display; High accuracy of measurement;Simple operation; Stable and durable.
(3)Density value of samples with temperature from normal to 100 centigrade can be measured.
(4)Take samples conveniently;50CC or less would be okay.
(5)It is very easy to clean measurement cup;can’t got the limitation of the size of pycnometer caliber.
(6)Adopt completed windproof and dustproof cover,which makes structure convenient and durable.
(7)Adopt completed stainless steel measuring hook.
(8)Coordinate with operation of thermostatic tank to measure the proportion with required
temperature.
(9)Function of displaying concentration of density and baume.Volatile liquid,corrosivity liquid,vicidity liquid,strong acid and strong lye liquid can be measured quickly.
(10)Interface of RS-232C is included.the printer of DE-40 is available to connect PC with the instrument.
Measurement Procedure:
Place beaker with samples on test board.and take off weight of pothook.
Hang standard weight on pothook and submerged in liquid to be test totally.and then press ENTER button to memory.Density valuve can be displayed.
Standard Accessories:
Host,measurement frame,DE-20A standard liquid measurement
assembly,tweezers,thermometer,100G weight,wind and dust cover,measurement
support,power transformer
DE-20A standard liquid measurement assembly:
Two stainless steel pothooks,one normal glass weight,one normal stainless steel
weigh,two beakers.
Optional Accessories:
DE-40 printer,DE-20B anti corrosive liquid measurement assembly.
Instruction Table:
|
Name/model |
DA-300W |
DE-120W |
|
Brand |
DAHOMETER |
DAHOMETER |
|
Density resolution |
0.001 g/cm3 |
0.0001 g/cm3 |
|
Density range |
0.001—99.999g/cm3 |
0.0001—99.9999g/cm3 |
|
Measurement type |
a:mobility liquid,vicious liquid,volatile liquid,corrosivity liquid,high temperature liquid,suspension liquid,emulsion and so on
b:alcohol,scaling powder,essence,blood,sodium chloride,glycerol,electrolyte, diesel,refrigerating, hydrofluoric acid,dichloromethane,vitriol |
|
|
Measurement Principle |
A.Archimedes principle displacement method;B.Constant volume method(pycnometer method) |
|
|
Measurement mode |
3 group |
|
|
Measurement time |
immediately |
|
|
Memory mode |
dynamic memory |
|
|
Result disply |
Density value and Baume |
|
|
Specific Gravity Measurement frame |
stainless steel specific gravity measurement frame |
|
|
Function of setting |
Temperature setting,solution density setting,measurement weights setting of weigh in the Normal Liquid and water |
|
|
Function of prompting alarm |
alarm rings when judge density unqualified. |
|
|
Standard weight setting |
set three different group of the weight of weight in air and in water |
|
|
Calibration mode |
auto correction with one button,auto detection. |
|
|
Measurement testing |
distilled testing |
|
|
Output mode |
standard interface of RS-232,output and Print testing data conveniently |
|
|
Standard accessories |
Host,measurement frame,DE-20A standard liquid measurement assembly,tweezers,thermometer,100G weight,wind and dust cover,measurement support,power transformer
DE-20A standard liquid measurement assembly: Two stainless steel pothooks,one normal glass weight,one normal stainless steel weigh,two beakers. |
|
|
Optional accessories |
DE-40 printer,DE-20B anti corrosive liquid measurement assembly |
|
|
power supply |
Defaulted as Europe type;other type can be optional |
|
|
Main feature |
data display,accuracy,speediness,convenience Durable,economy |
|
Packing size:42 X 16 X 32cm
Items will be shipped out within 2 days upon verification payment.
Items will be shipped out via:
- air shippment
- International Express: DHL/UPS/FEDEX/TNT .it will take around 5 to 7 days to get your door given considering everything goes well.
As leading manufacturer of densimeter,we guarantee below:
- 100% Competitive price we are the original manufacturer of densimeter for years, the large scale production make our products more competitive, that’s the reason we are very confident to offer the most possible competitive price for the same level testing instruments in the world.
- High quality standards we have the powerful professional researching and technology team to support quality;Our quality has been proved by the good market reaction for years;Our product are built to meet the industrial standards and global standards;Every instrument get checked and approved by our QC before delivery.
- Faultless service we have the professional customer service team to provide the one to one service for you;we can help you to enjoy the one-stop service without any worries;we have the completed after-sales service policy and quality insurance policy;we guarantee instruments for one year and life-long maintenance(Gold Purity Tester for two years)
- Efficient logistics we have the stable partner to help us to deliver the goods to the any corner of the worldwide shortly.Air shipment;International express:DHL/UPS/FEDEX/TNT(5 days to 7 days)
- OEM service We are the original manufacturer of densimeter,that is verified by the third party and Alibaba on site;We can provide you OEM service and print your logo on the instruments
