New 371HP 12cm3 8×4 HOWO Concrete Cement Transit Mixer Truck

ر.س22,907.44

Qty:

New 371HP 12cm3 8×4 HOWO Concrete Cement Transit Mixer Truck

1). Using hydraulic transmission device, do not rely on external force, easy to use, continuous rotation of the tank during transport, commercial concrete does not precipitate, not segregation.
2). Easy to operate, a handle to achieve centralized control of mixing tank, the configuration mature and reliable, easy maintenance.
3). Low noise, no smoke, safe and reliable.
4). The use of high-intensity wear-resistant steel plate mixing tank, durable.
5). Unique inlet setting, easy to spread material.
6). Small size, transport flexibility, easy operation and maintenance, power consumption, energy-saving effect is remarkable.
7). Blade design is reasonable, the discharge residue rate is low.

Concrete mixer truck (4)



Product Description

Specifications of  Concrete Mixer Truck 12 cubic meters

Sinotruk Howo 8×4 Mixer Truck – 12 CBM

Chassis Model

ZZ1317N3261W ( Left Hand Driving Type)

Dimension (L×W×H)mm

10207*2496*3785mm

Wheel base mm

1800+3200+1350

Cabin

HW76, one sleeper with air-conditioner.

Engine

WD615.47, Euro 2, 336HP

Transmission

HW19710, 10F & 2R

Steering

ZF8118, power steering with hydraulic system.

Front Axle

HF9, 1×9000 KGS

Rear Axle

HC16, 2×16000 KGS

Tyres

1200R20, 10+1tyres

Frame

8+5 mm double strengthen frame

Fuel Tank Volume

300L

Mixer Pump

Eaton (USA Brand)

Motor

Eaton (USA Brand)

Speed Reducer

Bonfiglioli (Italy Brand)

Agitating Capacity

12 Cubic Meters

Geometric Volume

20.4m3

Water Tank Volume

400L

Drum rotating

12.4°

Agitator rotaion speed

0-18r/min

Feeding speed

>3m3/min



concrete mixer truck (27)





Details of Product

Cement Mixer Truckconcrete mixer truck (7)concrete mixer truck (1)

 Cabin:Standard cab with One sleeper, with 4-point support fully

floating suspension and shock absorbers, with air conditioner.
