MZ-G150 Liquid Densimeter , Ethanol Hydrometer , Electronic Liquid Density Meter

ر.س1,711.52

Clear
Qty:
Compare

Request quotation for: MZ-G150 Liquid Densimeter , Ethanol Hydrometer , Electronic Liquid Density Meter

MZ-G150 Liquid Densimeter, Ethanol Hydrometer, Electronic Liquid Density Meter





Free Shipping

Original Manufacturer

Warranty for 3 Years





WE WILL REPLACE A NEW MACHINE FOR YOU IF THERE ARE SOME TROUBLES WHICH MUST RETURN THE MACHINE TO CHINA TO REPAIR DURING USE.
Confidence in product quality !!





Warm Tips:

The price includes the costs of delivery and insurance, which varies in types. For details, please contact our client service.







Suitable for:
Chemical solution, Food Industry, Aquaculture Industry, Mouth wash,Medicament, Research Laboratory



Principle:

In accordance with GB/T13531, T5526, T5009, ASTM, JIS, ISO standards, and by adopting the buoyancy method and water displacement method of Archimedean principle, the density and concentration can be showed rapidly.



Functions:

(1)1.Using German HBM sensor, the reading is stable, the overload is automatically protected   , the sturdy and durable, the warranty is three years.Density value can be showed by one procedure,and repeatedly continuous rapid measurement can be worked.

(2).Imported silent mechanical buttons in Japan, you can respond to readings with a touch of 0.1 seconds, sensitive and fast, lifetime warranty.(2)Digital display; High accuracy of measurement;Simple operation; Stable and durable.

(3)Density value of samples with temperature from normal to 250centigrade can be measured.

(4)Take samples conveniently;50CC or less would be okay.

(5)It is very easy to clean measurement cup,and can’t got the limitation of the size of pycnometer caliber.

(6)Adopt completed windproof and dustproof cover,which makes the structure convenient and durable.

(7)Adopt completed stainless steel measuring hook.

(8)Coordinate with operation of thermostatic tank to measure the proportion with required temperature.

(9)Function of displaying concentration,density .Volatile liquid,corrosivity liquid,vicidity liquid,strong acid and strong lye liquid can be measured quickly.

(10)Interface of RS-232C is included.the printer of MZ-P1 is available to connect PC with instrument.

Specifications:

MZ-G150 Liquid Densimeter, Ethanol Hydrometer, Electronic Liquid Density Meter

Model

MZ-G200

MZ-G300

MZ-G150

Weighing range:

0.01-200g

0.01g~300g

0.001g-150g

Density accuracy:

0.001 g/cm3

0.001 g/cm3

0.0001g/cm3

Density repeatability:

±0.003g/cm3

±0.001g/cm3

±0.0001g/cm3

Concentration repeatability:

±0.1%~0.001% optional (repetitive) with error compensation

Density, concentration range:

0.001~99.999g/cm³,0.1%~100%

Measurement type:





Any fluid liquid can be measured (true solution, dispersion, suspension, emulsion, viscous liquid, slurry, etc.), such as: flux, pine perfume, ethanol, ethylene glycol, methanol, Sulfuric acid, copper sulfate, sodium hydroxide, potassium hydroxide, sodium chloride, alcohol, electrolyte, vegetable oil, grease, resin, flour, soy milk, milk, etc.)

Measuring principle:

The principle of the Archimedes replacement method, the test time is about 5 seconds.

Liquid mode measurement step:

Take about 50ml of sample, put the standard block in the sample, one-click direct reading density (specific gravity), concentration%

The results show:

Liquid density, specific gravity, concentration%

Parameter setting:

Standard block density, concentration linear parameter, specific gravity upper and lower limits can be set

Correction method:

One-button automatic correction

Output method:

RS-232C standard communication interface, convenient test data output and printing

Power supply:

AC~220V / 50HZ(The export power supply needs to be customized, and it can be noted before ordering.)

Accessories:

1.Liquid specialized frame    2. Teflon weight (fall resistant, acid and alkali resistant)  3.Hook    4.50CC beaker    5. Support plate      6. Main-body    7. Calibration weight

8. AC adaptor             9. Thermometer

Measuring Procedure:MZ-G.png



Detailed images:

MZ-G300MZ-G150



Company Information

 Mayzum (Our brand) specialized in producing and selling professional densitometer for 11 years and we can provide professional density test instrument solution for you

1. Different program functions can be customized according to customer requirements;

2. We can provide OEM service.

3. Looking for brand agent wholesales all over the world.

 QQ20200416100423
