CTCNC21C MINI CNC LATHE
1. The machine can process precisely internal or external diameter, face, taper and threading with high efficiency. 2. Small size,lower energy consumption, easy operation,suitable for small processing. 3. High-quality spindle by high-precision grinding and support by Angular contact bearing. 4. Induction harden bed-way,Bed saddle with plastic sticker can improve the accuracy and service life of machine. 5. Processing of complex parts, fully functional, economical.
Introduction to Parameters:
Maximum turning diameter 210 mm Rotation diameter of middle carriage 100 mm Maximum length of turning workpiece 250 mm Spindle diameter 26 mm X/Z axis travel 110×300 mm Electric square knife holder 12x12mm Tailstock sleeve taper MT2 Spindle taper MT4 Tailstock sleeve diameter 22 mm Tailstock sleeve stroke 50 mm Spindle accuracy ＜0.01mm Positioning accuracy 0.02 mm Repeatability 0.01mm Movement speed of two axes Max. 6000 RPM Two-axis feed rate 1~4000 RPM Spindle speed 0-3000r/min Spindle Servo Motor 1.88KW / 6N.m Two-axis servo motor 750w / 2.4N.m Pump power 40w Voltage 220V / 50HZ Net weight ≈376 kg Machine size (LxWxH) ≈1250×680×1200mm Package Size ≈1350×750×1400mm
is one of the largest lathe manufacturers in China. We have 12 years of production and R&D experience. In 2019, we set up a foreign trade export sales department. We specialize in independent research and development, production, sales and after-sales service of small household machine tools, lathes, drilling and milling machines, small multifunctional drilling and milling machines, small CNC machines and cutting machines. Our products have been exported to more than 30 countries such as Europe and the United States, and these machines are used in many industries and fields. We always insist on technological innovation and standard production process. We have after-sales engineers and technicians engaged in mechanical design for many years.
