Modbus RS485 sensor soil moisture probe Meter
Product Description
Our sensor for soil temperature and moisture measurement, compared with the original German high-precision sensors and soil drying method of weighing the actual calibration, high precision, fast response, stable output. By the soil salt content of small, suitable for all kinds of soil. Long-term buried in the soil, resistant to long-term electrolysis, corrosion resistance, vacuum potting, completely waterproof.
|
RS485 OUTPUT
|
ANALOG OUTPUT
|
||||
|
Power supply
|
5~24V DC
|
Power supply
|
12~30V DC
|
||
|
Power consumption
|
30mA*24V DC
|
Power consumption
|
60mA*24V DC
|
||
|
Moisture range
|
0~100%RH
|
Moisture range
|
0~100%RH
|
||
|
Accuracy
|
±3%RH
|
Accuracy
|
±3%RH
|
||
|
Operating temperature
|
-40℃~60℃
|
Operating temperature
|
-40℃~60℃
|
||
|
Response time
|
<1s
|
Response time
|
<1s
|
||
|
Output signal
|
RS485
|
Output signal
|
4-20ma/0-5v/0-10v
|
||
|
Protection level
|
IP68
|
Protection level
|
IP68
|
||
|
Probe material
|
304 stainless steel
|
Probe material
|
304 stainless steel
|
||
Other types of soil sensors for choose
Installation Instructions
|
RS485 OUTPUT
|
||||
|
Line color
|
Description
|
Remark
|
||
|
Brown
|
Power supply
|
5 ~ 24V DC
|
||
|
Blue
|
power ground
|
GND
|
||
|
Black
|
485-A
|
485-A
|
||
|
Gray
|
485-B
|
485-B
|
||
|
Shield
|
Connect the negative pole of the power supply to the acquisition mode, and connect the positive pole of the power supply to the setting mode
|
|||
|
4-20ma,0-5v,0-10v OUTPUT
|
||||
|
color
|
Description
|
Remark
|
||
|
Brown
|
Positive power supply
|
10 ~ 30V DC
|
||
|
Blue
|
Negative power supply, negative temperature signal, negative moisture signal
|
GND
|
||
|
Black
|
positive Water signal
|
To ground
|
||
|
Grey
|
positive temperature signal
|
To ground
|
||
Why Choose Us
FEATURES
♦ Compact size, easy to carry, easy to install, operate and maintain
♦ Good sealing, can be buried in soil of different depth for a long time
♦ High accuracy and reliable performance
♦ Fast response and high data transmission efficiency
♦ Good sealing, can be buried in soil of different depth for a long time
♦ High accuracy and reliable performance
♦ Fast response and high data transmission efficiency
ADVANTAGES:
1: High precision measurement, rapid response, good exchange ability
2: Good tightness, corrosion resistance, can be used in the soil for a long time.
3: Flame retardant epoxy resin curing, completely waterproof, can withstand strong external impact.
4: Steel needles are made of high quality materials that can with stand long-term electrolysis , acid and alkali corrosion in soil.
5: Steel needles are made of high quality materials that can withstand long-term.
2: Good tightness, corrosion resistance, can be used in the soil for a long time.
3: Flame retardant epoxy resin curing, completely waterproof, can withstand strong external impact.
4: Steel needles are made of high quality materials that can with stand long-term electrolysis , acid and alkali corrosion in soil.
5: Steel needles are made of high quality materials that can withstand long-term.
WHY CHOOSE US?
Before-sale service:
1.OEM price,delivery sensors in 3 days.
2.Offer CE, ISO, FCC, ROHS Certificats.
3.24 hours service online.
4.Welcome to visit our factory.
5.Sample is avaliable.
sensor soil moisture
After-sale service:
1.2 years warranty for our sensors.
2.Offer 24 hours free technical support
3.Free cloud server
Application
1.Agriculture irrigation 2. Greenhouse 3.Grass farm 4.Environment monitoring 5.Water conservation 6.Soil testing
Company Introduction
Shandong Renke Control Technology Co.,Ltd. is a leading environmental monitoring high technology enterprise in China.
Renke is engaged in industrial sensor, communication gateway, industrial data platform, cloud computing service,and measurement control technology solution. We have won good reputation for high quality products and sincere service. Renke insists on the policy that”technology first, exquisite design, customer satisfied” we are careful with every detail. Every drawing has to be considered and revised repeatedly. Every products is the thought of designer.
Renke is engaged in industrial sensor, communication gateway, industrial data platform, cloud computing service,and measurement control technology solution. We have won good reputation for high quality products and sincere service. Renke insists on the policy that”technology first, exquisite design, customer satisfied” we are careful with every detail. Every drawing has to be considered and revised repeatedly. Every products is the thought of designer.
FAQ
Q: Are you manufacturer?
A: Yes, We are Tranmitter manufacturer and exporter in china over 10 years experience with CE, ROHS, FCC, ISO and 11patents.
soil moisture meter soil moisture meter soil moisture meter
Q: Do you offer the OEM service?
A: Yes, we can offer OEM service and design the shell and logo for you.
soil moisture meter soil moisture meter soil moisture meter
Q: Do you offer free samples?
A: Sorry , we do not offer free samples. After you bulk order, we will deduct the sample fee from second order.
soil moisture meter soil moisture meter soil moisture meter
Q: What payment ways do you accept?
A: You can pay us by T/T , PayPal , and West Union .
soil moisture meter soil moisture meter soil moisture meter
Q: What is your delivery time?
A: It is in 3-5 working days since the payment confirmed. If your order is over 3000pcs, we need 10 days.
soil moisture meter soil moisture meter soil moisture meter
Q: How is your quality assurance service?
A: 24 months quality guarantee.
soil moisture meter soil moisture meter soil moisture meter
Q: Could we make a visit to your factory?
A: Yes, you are welcomed .
A: Yes, We are Tranmitter manufacturer and exporter in china over 10 years experience with CE, ROHS, FCC, ISO and 11patents.
soil moisture meter soil moisture meter soil moisture meter
Q: Do you offer the OEM service?
A: Yes, we can offer OEM service and design the shell and logo for you.
soil moisture meter soil moisture meter soil moisture meter
Q: Do you offer free samples?
A: Sorry , we do not offer free samples. After you bulk order, we will deduct the sample fee from second order.
soil moisture meter soil moisture meter soil moisture meter
Q: What payment ways do you accept?
A: You can pay us by T/T , PayPal , and West Union .
soil moisture meter soil moisture meter soil moisture meter
Q: What is your delivery time?
A: It is in 3-5 working days since the payment confirmed. If your order is over 3000pcs, we need 10 days.
soil moisture meter soil moisture meter soil moisture meter
Q: How is your quality assurance service?
A: 24 months quality guarantee.
soil moisture meter soil moisture meter soil moisture meter
Q: Could we make a visit to your factory?
A: Yes, you are welcomed .
