Mobile concrete mixer with pump diesel concrete pumps pipe
Trailer-mounted concrete pump:
The concrete pump is composed of a pump body and a delivery pipe. It is a machine that uses pressure to continuously transport concrete along pipelines. It is mainly used in construction of houses, bridges and tunnels.
| Distribution valve form | S-type pipe valve | |
| Theoretical output pressure (MPa) | high pressure / low pressure | 12.5/7.4 |
| Theoretical delivery capacity (m3/m) | high pressure/low pressure | 37/64 |
| Maximum pumping distance (m) | 125A | horizontal 800 vertical 200 |
| 150A | horizontal 850 vertical 210 | |
| Motor power (KW) | 90 | |
| High and low voltage switch | Yes | |
| Maximum aggregate size (mm) | 125A 150A | |
| Main cylinder diameter×maximum stroke (mm) | 125×1800 | |
| Hydraulic oil tank capacity (L) | 560 | |
| Concrete slump range (cm) | 8-23 | |
| Dimensions (length * width * height (mm) | 6200*2050*2200 | |
| Overall weight (kg) | 6200 | |
Performance characteristics of concrete pump:
1. S-pipe distribution valve is adopted to meet the pumping of small aggregate concrete and mortar
2. The main oil pump adopts deformed plunger pump with high efficiency and strong pressure.
3. The hydraulic system adopts independent three circuit control, high reliability spectacle plate and cutting ring adopt cemented carbide, with wear resistance and long service life
4. The pumping mechanism adopts double cylinder piston type, with advanced performance and good continuity.
