tube, flow range up to 1740 ml/min. The shell of pump head is made of PPS material and the roller is made of 304 SSS material. The
roller has high strength, better wear resistance, strong chemical corrosion resistance, and it can be disinfected at high
temperature .
|
Order list for the small peristaltic pump OEM202 .
Noted:
1.The defaulted model we will send is 202-1-6 with DC24V motor and flow is 1740ml/min
2.If you need other model pls contact us .
3, The speed controller is not defaulted, if you need pls contact our sales.
4, The defaulted pump head material is pps (black)
5, Support multiple channels customized, more info ,pls contact us.
|
||||||||||||||
|
Order Number
|
Model
|
Pump head
|
Motor Voltage
|
Motor Power
|
Motor Speed
|
Tube model
|
Flow rate
(ml/min)
|
|||||||
|
202-1-6
|
OEM202-1
|
YZ2515x
|
DC24V
|
15W
|
600rpm
|
24#
|
1740
|
|||||||
|
202-1-4
|
OEM202-1
|
YZ2515x
|
DC24V
|
15W
|
400rpm
|
24#
|
1160
|
|||||||
|
202-1-6
|
OEM202-1
|
YZ2515x
|
DC24V
|
15W
|
600rpm
|
24#
|
1740
|
|||||||
|
202-1-4
|
OEM202-1
|
YZ2515x
|
DC24V
|
15W
|
400rpm
|
24#
|
1160
|
|||||||
|
202-2-6
|
OEM202-2
|
YZ2515x
|
DC12V
|
15W
|
600rpm
|
24#
|
1740
|
|||||||
|
202-2-4
|
OEM202-2
|
YZ2515x
|
DC12V
|
15W
|
400rpm
|
24#
|
1160
|
|||||||
|
202-2-6
|
OEM202-2
|
YZ2515x
|
DC12V
|
15W
|
600rpm
|
24#
|
1740
|
|||||||
|
202-2-4
|
OEM202-2
|
YZ2515x
|
DC12V
|
15W
|
400rpm
|
24#
|
1160
|
|||||||
|
Tube specifications for the pump YZ2515x
Noted : The standard tube which will come with the pump is model 24#, If you need other tube model , pls contact our sales in
advance. |
||||||||||
|
Tube model
|
ID(mm)
|
OD(mm)
|
Standard material
|
max flow with 400rpm (ml/min)
|
max flow with 600rpm (ml/min)
|
|||||
|
15#
|
4.8
|
8
|
Silicon tube
|
680
|
1020
|
|||||
|
24#
|
6.4
|
11.2
|
Silicon tube
|
1160
|
1740
|
|||||
Pump head with PPS material (Black)
etc.- Refrigeration / Condensate Removal- Analytical / Fluid Transfer, Wastes- Commercial Exercise Eqpt. / Lubrication- Grease Trap Control /etc..
Pump head with PSF material (White)
Application For additive feeding
Application For waste water application
Baoding Chuang Rui Precision Pump Co., Ltd. Started production of the peristaltic pump from 2006 . We are a innovative company focus on research and development, production and marketing of peristaltic pump.
We aim to “Produce CR pump to the easier life.
With 10 years professional experience of Peristaltic pump Tubing pump Liquid handling pump . Now we independent research and development of more than 30 series, over 200 kinds of products. We not only produce the standard peristaltic pump, Peristaltic pump filling system , but also focus on the ideal OEM design and customization. According to the actual needs of customers to produce the ideal OEM peristaltic pump .Widely used in various industries of pharmaceutical industry, fine chemical industry, environmental protection, biochemical industry, laboratory & research application etc.
We are confident that we can offer the top quality and service for our customers. And we are trying our best to be the top one in our peristaltic pump field.
Our professional team can insure fluent communication, as well as perfect after-sale service.
Chuang Rui make sure that our factory can supply peristaltic pump of best price, high quality, so you will be full of confidence for your market expansion.
replaceable tubes allow you to switch from one liquid to another in the shortest amount of time.
No need to rinse and disassemble after the flushable product, you only need to replace the peristaltic pump tubing
CR Peristaltic pump with high precision
The calibration function can ensure the filling accuracy for each dose. The suck-back function prevents liquid (reverse): in the dispense mode, after the end of the direct cycle, the return stroke is initiated to prevent the liquid from flowing out of the pump tube during the stop.
CR peristaltic pump is non-pollution: the fluid only contacts the pump tube and does not touch the pump body;
CR Peristaltic pump is Versatility
CR peristaltic pump can be used with a variety of products and can be used in a variety of industries.
CR peristaltic pump is easy to work
After the power is turned off and on, the control system maintains the current settings (pump head tubing model and other parameters).
CR peristaltic pump with good sealing: It has the good self-priming ability and can be idling to prevent back flow.
CR peristaltic pump with Low shear: ideal for conveying shear sensitive, aggressive fluids
- 1.The package contains a peristaltic pump and its accessories.
2.foam and carton packaging can protect the safety of the peristaltic pump during transportation.
3.If you have other packaging needs, please contact us in time.
