| CT6140 HEAVY DUTY LATHE FROM CTMACH |
|
Model: CT6140 |
|
|
Swing over bed |
400mm |
|
Swivel diameter of tool post |
240mm |
|
Distance between centers |
1000mm |
|
Large Carriage Travel |
900mm |
|
Middle Carriage Travel |
240mm |
|
Small Carriage Travel |
140mm |
|
Travel of Tail-stock Sleeve |
130mm |
|
Taper of Tail-stock |
MT4 |
|
Spindle Bore |
48mm |
|
Spindle Taper |
MT6 |
|
Spindle Positive and Negative Speed/Grade |
25-1600r/min(12) |
|
Longitudinal Feed/Grade |
0.04-2.16mm/r(138) |
|
Transverse Feed/Grade |
0.02-1.08mm/r(138) |
|
Metric Thread/Grade |
0.45-20mm/r(30) |
|
Inch Thread/Grade |
80-1¾T.P.I(35) |
|
Modulus Thread/Grade |
0.25-10mm(25) |
|
Diameter Pitch Thread/Grade |
160-3½DP(30) |
|
Main Motor Power(double speed) |
YD132M-8/4 3/4.5KW |
|
Main Motor Speed |
750/1500r/min |
|
Cooling Pump Motor |
AYB-20TH 0.115KW |
|
Machine Dimension |
2200*900*1250mm |
|
Net Weight |
1450KG |
|
Gross Weight |
1850KG |
|
Packing Size |
2410*1160*1600mm |
