Single head cutting saw/PVC and Aluminium cutting machine/window and door making machine
Main features
1). Special for aluminum and PVC profile cutting at 0~180 degree, with mechanical stops between each 15 degree
2). Carbide saw blade give accurate processing and high endurance
3). To provide bracket with scale ruler for material locating
Technical Parameters
Brand |
Mingmei |
Model |
LSJ-450A |
Main motor power |
1.5KW |
Main motor rotation speed |
2800r/min |
Saw cutting(W*H) |
120*200mm |
Saw blade dimension |
Ø450*Ø30 |
Saw blade swing angle |
45°~90° |
Working voltage |
380V 50HZ |
Repeat locating length |
≤0.05mm |
Angle cutting tolerance |
±5’ |
Plainness of cutting surface |
≤0.10mm |
Cutting profile surface roughness |
Ra12.5Um |
Size |
700*1300*1500mm |
Weight |
280KGS |
MAG group co., LTD. Is a window machine and related materials industry group in shandong province. Our products cover window making machine, window glass machine, curtain wall processing equipment, CNC machining center, insulating glass building materials, etc.
With the progress of internationalization and globalization, we have 5 subsidiaries and 4 major production bases, we are the building equipment domain product system complete manufacturer.
At present, our products have been sold to more than 50 countries and regions. Relying on the sales centers of various countries, we also established service centers to provide customers with products and services efficiently.
In the future, we will continue to uphold the “making building more energy-saving and make life getting better ” brand of faith, with new attitude, to provide customers with more cost-effective products and services, to create the bright, comfortable, high quality window and doors productions.
