Product Application
LONES MACHINERY was established in 2014. It is a professional manufacturer and exporter
specializing in the design, manufacture and sales of semi automatic pet blow molding machine, full automatic pet bottle making machine and pet bottle molds; and provides PET One-stop solutions for a series of products such as PET preform moulds and plastic cap molds; in order to meet the needs of customers in different countries and regions, we continue to update processing equipment, improve processing accuracy and optimize machine design; the factory runs synchronously with production and management, greatly improves the timeliness of manufacturing equipment; all our equipment meets international quality standards and is greatly appreciated all over the world.
LS-A6 FULL AUTOMATIC PET BLOW MOULDING MACHINE
|
||||||
THEORETICAL OUTPUT
|
7000BPH for 500ml bottle
|
|||||
MAX. CONTAINER VOLUME
|
2L
|
|||||
MAX.NECK DIAMETER
|
45MM
|
|||||
MAX.CONTAINER DIAMETER
|
100MM
|
|||||
MAX.CONTAINER HEIGHT
|
340MM
|
|||||
NUMBER OF CAVITY
|
6CAVITY
|
|||||
TOTAL POWER
|
55KW
|
|||||
USE POWER
|
40KW
|
|||||
WORKING PRESSURE
|
1.0MPA
|
|||||
BLOWING PRESSURE
|
≤3.0MPA
|
|||||
MACHINE WEIGHT
|
5000KGS
|
|||||
MACHINE SIZE
|
5.3×2.5×2.1m / 1.2×2.3×2.8m
|



Main Features
1.Full servo motor drive mode, running stable, energy saving and high efficiency, low maintenance and can directly connect to the filling line
2.Adopting world famous brand micro PLC controller,the operating language can be customized
3.Special mold locking system enables faster mould locking while saves the air a lot
4.Non-pause rotation and constant temperature control oven to heat preforms and high speed mold clamping , saving more than 30% energy
5.Suitable for carbonated drinks, oil, hot filling tea ,juice and water bottles etc
