Lcd Digital Display Laboratory Portable Electrical Overhead Stirrer
Note:
We have four different series about Overhead stirrer (HM-S,HM-T,HM-C,HM-P ).
The features as below:
|
HM-S series
|
Digital LED display stirring speed, Round plate. |
|
|
Digital LCD display stirring speed and timer ,speed control with closed MCU control, Max timer set: 9999 min, Round plate. |
|
|
Digital LED display stirring speed,speed control with closed MCU control, Rotary encoder operation,Square plate,Constand stir speed. |
|
|
New model,digital display stirring speed and time,Micro-processor(Programmable)control ,FWD time 1 REV time 3 interval time Max 255sec (Max timer set: 9999 min) , Round plate,laboratory chemical overhead stirrer. |
HM-S series
|
Model |
HM-40S |
HM-100S |
HM-150S |
HM-250S |
|
Motor Power |
40W |
100 W |
150 W |
250W |
|
Motor Type |
Brushless DC Motor |
|||
|
Motor Torque |
200 m N.M |
450 m N.M |
600 m N.M |
1 N.M |
|
Voltage |
220V +/- 10%,or 110V +/- 10% |
|||
|
Rotational Speed Range |
60- 1500rpm / 60- 2000rpm |
|||
|
Working Time |
Continue |
|||
|
Stir Capacity |
50ml – 18 L |
50ml – 40 L |
50ml – 80 L |
50ml – 100 L |
|
Stir speed |
Digital display .LED |
|||
|
Stir Rod Length |
350mm |
350mm |
3500 |
3500 |
|
Stir Rod Material |
PTFE |
Stainless Steel |
Stainless Steel |
Stainless Steel |
|
Holder Length |
700mm |
700mm |
700mm |
700mm |
|
Chuck Clamping Range |
Ø1.5-10 |
Ø1.5-10 |
Ø2-13 |
Ø2-13 |
|
Product Dimension (mm) |
390 x 93x 160 |
390 x 93x 160 |
390 x 93x 180 |
390 x 93x 180 |
|
Gross weight (KG ) |
10.4 |
12.1 |
12.5 |
13 |
