Technical Data
| Model | RE-505 | RE-510 | RE-520 | RE-550 |
| Rotate speed of main engine (rpm) | 10-140 | 20-130 | 20-130 | 20-110 |
| Heating power (Kw) | 1.6 | 2.5 | 4.3 | 5.5 |
| Rotary flask (L) | 5 | 10 | 20 | 50 |
| Receiving flask (L) | 3 | 5 | 10 | 20 |
| Evaporative capacity (L/h) |
Water ≥2 Alcohol ≥4 |
Water ≥3.2 Alcohol ≥6.5 |
Water ≥5 Alcohol ≥11 |
Water ≥9 Alcohol ≥19 |
| Complete machine power | 2kw | 3kw | 5kw | 6.5kw |
| Dimension (mm) | 765×400×1070 | 920×550×1700 | 1250×600×2100 | 1320×770×2340 |
| Speed regulation of main engine | Digital variable-frequency stepless speed regulation | |||
| Temperature control | Digital temperature control | |||
| Maximum vacuum degree | 399.9Pa(under 3mmHg) | |||
| Motor Power | 250w | |||
| Temperature Range | Room Temp. to 180℃ | |||
| Voltage | Single pahse220V,50/60Hz (Customize: 110V) | |||
| Bath Type | Oil/Water Bath | |||
| Bath Lift Type | Motor lift | |||
| Glass Material | Borosilicate Glass 3.3 | |||
| Water bath pot material | Stainless steel | |||
| Casters | 4pcs | |||
