KC901S+ vector network analyzer antenna RF spectrum field multimeter SWR standing wave testing 4G
Including vector reflection, scalar transmission, spectrum, signal source and other functions, to resolve common radio frequency testing. Applicable in communications engineering, radio and television engineering, radio enthusiasts, research and education and other fields
901S+ is an upgraded version of 901S, the frequencies is up to 4G.
KC901S+ is a universal vector antenna analyzer. It supports the analysis of single port vector network analysis and dual port scalar network analysis, meanwhile expanding the spectrum, field strength and signal generator convenient function. KC901S+ has professional practicality, and includes the battery which supports 5 hours large work load, the volume is just 1 dm3, weight is only 1 kg, bring a new experience for the user.
Main features*
9KHz-4GHzfrequency range
1Hz frequency resolution
Reliable accuracy and stability
Two frequency conversion, external interference resistance
Rich functionality and lightweight design
Main functions
Transmission test(scalar:debug filter,amplifier,test antenna directivity)
Reflection test(vector:regulate impedance matching, check the antenna system quality)
Spectrum display and field strength observation**(Test radio transmitter performance and find interference sources)
Output one frequency point signal individually
Suggesting application
KC901S+ is mainly used for debugging various RF circuits, such as filters, amplifiers, splitter, combiner, test input and output impedance, the quality evaluation of antenna system, signal amplitude detection of equipment at all levels. In most frequency bands, it also can measure field strength, and do interference search and other work.
This instrument can effectively improve work efficiency, reduce the carrying burden, improve the quality of work. 901S is a test tool for every electronic engineers, also as a regular instrument of professional communication engineering, and radio television transmitting station technical personnel.
The difference between 901S+ and 901S
901S+ is the upgraded product of 901S
901S+ adopts all digital intermediate frequency technology
901S+ the trace noise has improved more observably than 901
The electric bridge structure of 901S is improved, its nonlinear effect is smaller than 901S, and the accuracy of impedance test is improved
Based on the improvements of the electric bridge, the 901S+ can support low to 9KHz of S11 measurements, and the directionality is still good at this time
The spectrum function of 901S+ shares a port with the S11 function, and the port usage in the transmission test is the opposite of 901S
The S21 function of 901S+ is also vector, and the introduction of phase can provide more intuitive trend judgment
The frequency range of 901S+ is 9KHz – 4.1GHz.
901S+ analysis bandwidth (RBW) has four choices, respectively are 1KHz, 3KHz, 10KHz, 30KHz, spectrum function is stronger than 901S
Note1:Unless otherwise specified, all indicators are measured in the medium speed mode, 10KHz RBW, 0 output attenuation, temperature 25 ℃, and through the user calibration. A few accidental or abnormal data permanent period may exceed the range of technical parameters table.
Note2:When the battery is powered, the range depends on the temperature characteristics of the battery. It exceeds 0… 45℃ should be re calibrated when the equipment is preheated and stable. Especially within the range of -40~-20℃ , should be preheated for at least 5 minutes (and need to keep running). Due to heating of the equipment itself, the shell temperature may be 20℃ higher than the ambient temperature. In more than 45℃ environment, should avoid scalding. We must remove the battery when the environment temperature is closed to 65℃. Otherwise, the battery temperature may exceed 85 ℃ and cause danger.
Note3: Restricted to usage state only. Moisture storage measures must be adopted for long-term storage at a moisture level greater than 80%
