JINAN Derek CO2 laser cutting machine for Chassis cabinet production

ر.س21,349.41ر.س40,463.38

Clear
Qty:
Compare

Request quotation for: JINAN Derek CO2 laser cutting machine for Chassis cabinet production

Product Description

MIXEDApplicable  industriesApplicable materialsmixed210mixed2Mixed-CO2-lasermixed3

Model DRK1390M

X,Y Working Area

1300*900mm

Laser power

100w 130w 150w 180w 220W 300W

Laser type

CO2

Laser head NO.

One ( two heads option)

Reflector and focus mirrors

Imported

Linear rail

High quality Taiwan PMI square rail

Table type

One Knife table and one Honeycomb table



Cooling system

CW5200/CW6000 Water chiller

Other accessories

Exhaust fan,Air compressor,red dot etc all necessary

Engraving Speed





 0-60000mm/min

Cutting speed

 0-36000mm/min
Resetting position accuracy  ±0. 01mm
Control system RD6332M control system with WIFI wireless control
Software RDworks V8
Graphic format supported BMP, PLT, DST, DXF, AI, JPG, GIF, PGN, TIF
Software supported CorelDraw, PhotoShop, AutoCAD, TAJIMA,Artcut

Laser Output

1-100% Software Setting
Operating temperature 0 – 45℃
Operating humidity 5 – 95%
Working Mode 3-phase Stepper motor
Dichroic Cutting Up to 256 colors

Gross power

<2200W
Minimum shaping character English 1 x 1mm
Working Voltage 220V/50HZ -60HZ; single phase ( 110v option)

Company Information



Our Services



1.Within 7 days since your local customs clearance: if the machine’s any parts has any problems,we will change it free.

2. Exceed 7 days since your local customs clearance but within warranty period: if the machine parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.

3. Exceed warranty period: if the machine parts have any problems,we can offer new machine parts with cost price and you also should pay all the shipping cost.

4.We offer 24 hours technical support by call, email.

5.Our technician can give you remote guide online(Skype/MSN/What’s app/viber/Tel/Etc) if you have any question.

6.We can record videos of operating the machine.
