Wire Torsion And Wrapping Testing Machine
Product Description:
Metal Wire Torsion And Wrapping Testing Machine is a kind of new digital display type metal wire torsion and winding testing machine developed by our company. It is horizontal structure, which consists of loading, driving, winding, afterburner, tracking, etc. It is applicable to the torsion winding performance test for nominal diameter of Φ1-Φ10mm steel wire, copper, aluminum and its alloy wire; Rotation speed: 15,20,30,60 r / min adjustable. It main test the ability of wire in one-way, two-way torsion or winding to withstand plastic deformation and display wire surface and internal defects. And it equip with torsion, winding necessary accessories, to achieve a multi-purpose machine.
Parameter:
| Maximum distance between the two chuck | 500mm |
| Rotation speed | 15,20,30,60 |
| Jaw hardness | HRC50-60 |
| Tester working noise | <70db |
| Winding speed | 15,20,30,60rpm |
| Winding direction | Forward or reverse |
| Reverse speed | 0-60m/min (adjustable) |
| Motor power | 0.185KW |
| Rated voltage, frequency | 200V,50 Hz |
| 200V,50 Hz | 9999 |
| Torsion balance weight | 5*5kg |
Features:
1, PLC touch screen display:
Parameters: machine control related parameters;
Test conditions: test speed, test frequency, test angle direction, control conditions;
Test monitoring: the current equipment running status, such as the actual number of wire bending, angle, speed, etc .;
2, unattended: the device can be monitored by the sample circuit, automatically determine the sample off, detected when the circuit disconnect will automatically shut down, without staff supervision;
3, special fixture: According to the different diameter of the cable with the appropriate test fixture to meet the test requirements;
4, the machine performance: Kunlun tongtai LCD + Mitsubishi PLC + Panasonic servo motor, transmission components are imported products, smooth operation, high torque, high positioning accuracy, long life, low noise;
5, operability: machine side of the facade set aside maintenance cover, easy to use during the maintenance and repair.
Standard:
ISO 7802, GB/T 2976. ISO,ASTM,EN,etc
Product display:
DONGGUAN YUYANG INSTRUMENT CO.,LTD is Located in Wanjiang District (Dongguan City, Guangdong Province,China),a famous historical town with prosperous industry and convenient transportation.
We are a high-tech enterprise which is specialized in developing and manufacturing Fire Testing Equipment, Building Material Fire Tester, Wire and Cable Fire Tester, Environmental Test Chamber, Textile Testing Equipment, Toys Testing Equipment and etc.
Decades of research and development strengthen the leading edge of YUYANG in this field, and established as an crucial role in R&D on high quality and high-cost performance of testing equipment. YUYANG’s testing equipment are widely used in various field: scientific institutions, colleges, inspection institutions, auto parts, electronics, electricals, lithium battery, LED, photoelectricity, mobile, plastic and rubber, display, telecommunication, chemical industry, aerospace, building material and product, wire and cable, toys, furniture, textile and fabrix, etc. All YUYANG testing equipment are designed according to international test standards, such as ISO, ASTM, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA,CEN and so on.
DONGGUAN YUYANG INSTRUMENT CO.,LTD looks forward to cooperating with customer all over the world.
If you are interested in any of our products or would like to discuss a custom order. Please feel free to contact us. We are looking forward to forming succesful business with new clients around the world in the near future.
