Product Introduction
Piston mortar pump can transport various media such as cement slurry, yellow mud, water glass, oil, water etc.
Main Application:
1. In building, for horizontal and vertical conveying mortar.
2. In chemical industry and papermaking industry, conveying slurry raw materials and waste materials.
3.The use of fly ash slurry in a power plant
4. Used for grouting in national defense and civil air defense engineering and mine tunnel construction.
5. Grouting reinforcement for bridges, culverts and slope protection in railway and highway construction.
6. In highway pavement maintenance, grouting is used for cement pavement collapse.
7. In prestressed construction projects, for mortar injection expansion.
8. In the water conservancy project, it is used to reinforce the dam.
9. In metallurgy, steel and other industries, it is used to maintain grouting for blast furnace and other equipments.
Detailed photos
Parameters
| Piston Mortar Pump | ||
| Model | HJB-3 | HJB-6 |
| Engine | Electric 380V three-phase 50Hz | |
| Power | 3 kw | 4 kw |
| Conveying Ability | 3 m³/h | 6 m³/h |
| Working Pressure | 1.5 Mpa | 3 Mpa |
| Type | Single Cylinder | Double Cylinder |
| Motor Speed | 1440 r/min | 1440 r/min |
| Conveying Distance | Level:50 m, Vertical: 20 m | Level:60 m, Vertical: 30 m |
| Outlet Pipe | Φ51 mm | Φ51 mm |
| Inlet Pipe | Φ32/38 mm | Φ32/38 mm |
| Dimensions | 1250x500x850 mm | 1250x500x850 mm |
| Weight | 250 kg | 320 kg |
Motar Pump details
(1) The V-belt and a pair of gears transmit the motor’s rotary motion to the crankshaft. The connecting rod and crosshead allow the piston to reciprocate. The gearbox is closed, and splashes are used to lubricate the moving parts.
(2) The mortar is sent to the air by the suction valve through the pump cylinder pressure, and the bleeder valve and pressure safety device are installed on the air chamber.
(3) The piston pump adopts the electrical automatic control safety device.
(4) When the air chamber pressure exceeds the rated working pressure, the main circuit main circuit is cut off through the control circuit to automatically stop the motor.
Working
Piston Pump can be widely used in grouting and water plugging in tunnels, mine excavation face, grouting and sealing of rock lanes and concrete boreholes, reinforcement of tunnel cracks, broken rock masses, evacuation rocks, anchor grouting, backfill grouting and prevention surface sinking, prevention of landslides, correction of grouting for building deflection and so on.
