Hot Sale Torque Brushless Professional Electric Screwdriver GES-3L
With conical design, good line of sight, it is easy to install and disassemble bits
It owns the patent for toque adjustment design, needs the matched tool to adjust the torque. Its torque is much more accurate and precise. (domestic first technology patent)
The internal stop device adopts magnetic induction system, it owns high sensitivity, short braking, low impact force, and it is not easy to be broken after being used a long time.
Internal gear assembly adopts high quality alloy steel, which is more durable and stable
Low vibration, noise, and electromagnetic interference, it fits environmental request, especially for dustfree working room.
The shape is designed according to ergonomics, it is small body, light weight, with resistance to impact, it will not be tired after worker uses it a long time, the working efficiency is improved too much
|
Model No |
GES-3L |
GES-5L |
GES-12L |
||
|
Input voltage |
DC-30V |
||||
|
Torque Range |
Kgf.cm |
0.3-3 |
0.5-5 |
2-12 |
|
|
Lbf.in |
0.26-2.604 |
0.434-4.34 |
1.736-10.416 |
||
|
N.m |
0.029-0.294 |
0.049-0.49 |
0.196-1.176 |
||
|
Torque accuracy |
+/-3% |
+/-3% |
+/-3% |
||
|
Torque adjustment |
stepless |
stepless |
stepless |
||
|
Torque adjustment mode |
Internal adjust |
Internal adjust |
Internal adjust |
||
|
Start mode |
Lever start |
Lever start |
Lever start |
||
|
Speed without loading r.p.m |
0-1000 |
0-1000 |
0-1000 |
||
|
Weight(g) |
350 |
350 |
350 |
||
|
Current without load |
0.3A |
0.3A |
0.3A |
||
|
Bits |
¢4/¢5 |
¢4/¢5 |
¢4/¢5 |
||
|
Screw type |
Mechanical tooth |
1.0-2.3 |
1.0-2.6 |
2.0-3.0 |
|
|
Self-tacking tooth |
1.0-2.0 |
1.0-2.3 |
2.0-2.5 |
||
Feature:
- Conical design, good line of sight, easy to disassemble and install.
- The torque adjusts the patent design, the professional tool adjusts the torque, the torque setting is more accurate, the torque
- precision is higher. (domestic first technology patent)
- The internal stop device adopts magnetic induction system, with high sensitivity, instantaneous braking, low impact force, and
- long-term use not easily damaged.
- The gear assembly is made of high quality alloy steel, which is more durable and stable.
- Low vibration, low noise, low electromagnetic interference, comply with environmental requirements, especially applicable to
- dustfree working environment.
- The outer type is designed according to ergonomic grip, small volume, light weight, impact resistance, comfortable use, long
- time use not easy to fatigue, improve production efficiency.
- The speed of 0-1000rpm can be adjusted to suit your different needs.
1.Good quality and competitive price.
2,Any Inquires will be replied within 24 hours.
3,All of our products 100% inspection before shipment, we guarantee to use our products safety.
4,OEM/ODM orders are warmly preferred.
5,We own the best after-sale service.Any problems occur,our team will do our best to solve for customers.
6,Faster delivery, sample order in stock, and 3-7 days after bulk production.
