Measurement |
Measure Singal |
Measure Accuracy |
Output |
Output Accuracy |
|
DC Voltage |
0.000—30.000 V
0.000—24.000 V
0.000—90.000 mV
-10.000 —80.000mV |
0.02%+3 counts (The upper display) 0.02%+ 3 counts (The lower display) 0.01%+ 10 counts 0.01 % + 10 counts (use the thermocouple jack ) |
0.000— 20.000 V 0.000—90.000 m V -10.000 mV— 80.000 mV |
0.02%+3 counts 0.01%+10 counts 0.01 % + 10 counts (use the thermocouple jack |
|
DC Current |
0.000—24.000 mA 0.000—24.000 mA |
0.02%+ 4 counts(The upper display) 0.02%+ 4 counts(The lower display) |
0.000—24.000 mA |
0.02%+ 4 counts |
|
Resistance |
0.00— 400.00Ω
400.0—4000.0Ω |
0.1Ω (4 wire), 0.15Ω (2 wire and 3 wire) 0.5Ω (4 wire), 1Ω (2 wire and 3 wire) |
5.00 — 400.00 Ω 400.0 —4000.0 Ω |
0.15 Ω (Excitation current 0.15 to 0.5 mA), 0.1Ω (Excitation current 0.5 to 2 mA) 0.5Ω(Excitation current 0.05 to 0.8 mA) |
PACKAGE:
For small items, we will fully pack with Yellow Tape to protect water.For standard carton we will pack with stretch film and psate with client’s shipping mark mentioning company name,carton number.
DELIVERY TIME:
We have all items in stock, for sample we can send out within 3 working days, for OEM we can send within 35 working days,mosty depends on the quantity and our sales season!
