3, Easy operation, free-maintaining.
4, For various complex strutam, such as pebble bed, aggregate bed.
5, Saving money, compact construction, easy moving.
6, For geological exploration, exploration of high building construction, riversconstruction, civil water well.
7, It can do standard penetration test, use auger drilling and sampling with solid stem and the triple rod jet grouting.
|
Main machine technical parameter
|
||
|
Drilling depth
|
200m
|
|
|
Drilling diameter
|
300mm
|
|
|
Drilling Pipe Diameter
|
50mm
|
|
|
Drilling Angle
|
90°～45°
|
|
|
Drilling Weight（no include power）
|
975kg
|
|
|
Unity Machine Dimesions
|
2.75×0.95×1.6 m
|
|
|
Spindle
|
||
|
spindle speed
|
64、128、287、557 r/min
|
|
|
Spindle stroke
|
450mm
|
|
|
Hoist
|
||
|
Max.single line hoisting capacity
|
2400kg
|
|
|
Reel lifting speed
|
17、35、75、151r/min
|
|
|
Reel diameter
|
140mm
|
|
|
Wirerope diameter
|
13mm
|
|
|
Wirerop cubic measure
|
35m
|
|
|
Hug folldgate diameter
|
260mm
|
|
|
Hug folldgate belt width
|
70mm
|
|
|
Distance between drill and hole
|
400mm
|
|
|
Power
|
||
|
Diesel engine
|
s1110 Model
|
|
|
Electric Motor
|
Y160M—4 ,15 kw 1440 r/min
|
|
|
Mud pump
|
||
|
Type
|
Horizontal single urn twin-action
|
|
|
Displacement
|
170L/min
|
|
|
Maximum pressure
|
3.0Mpa
|
|
|
Work pressure
|
1.5Mpa
|
|
|
Water inlet caliber
|
40mm
|
|
|
Water to exit caliber
|
30mm
|
|
|
Triangle conveyer belt
|
B1728 mm
|
|
|
Hydraulic pump
|
||
|
Specification
|
CBT—F—314
|
|
|
Triangle conveyer belt
|
B1100*1
|
|
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
