Product Description
Specification
|
item
|
value
|
|
Warranty
|
1 year
|
|
Certification
|
GS
|
|
Customized support
|
OEM
|
|
Place of Origin
|
GUA
|
|
Brand Name
|
hantek
|
|
Model Number
|
2d82
|
|
Brand Name
|
2d82auto kit 3
|
|
Display Resolution
|
320 horizontal by 240 vertical pixels
|
|
Operating Temperature:
|
re: 0~50 °C (32~122 °F)
|
|
Display Type
|
2.8 inch64K color TFT
|
|
Cooling Method:
|
Convection
|
|
Dimension:
|
199 x 98x 40mm
|
|
Fuse
|
T, 3A
|
|
Model Numbe
|
2d82auto kit 3
|
Packing & Delivery
1 pc /corton
|
General Specifications
|
||||||||
|
Display
|
||||||||
|
Display Type
|
2.8 inch64K color TFT
|
|||||||
|
Display Resolution
|
320 horizontal by 240 vertical pixels
|
|||||||
|
Display Contrast
|
Adjustable
|
|||||||
|
Power Supply
|
||||||||
|
Supply Voltage
|
100V-240VAC, 50Hz-60Hz; DC INPUT: 5VDC, 2A
|
|||||||
|
Power Consumption
|
<2.5W
|
|||||||
|
Fuse
|
T, 3A
|
|||||||
|
Battery
|
2600mA*2
|
|||||||
|
Environmental
|
||||||||
|
Operating Temperature
|
0~50 °C (32~122 °F)
|
|||||||
|
Storage Temperature
|
-40~+71 °C (-40~159.8 °F)
|
|||||||
|
Humidity
|
≤+104℉(≤+40°C): ≤90% relative humidity
|
|||||||
|
106℉~122℉ (+41°C ~50°C): ≤60% relative humidity
|
||||||||
|
Cooling Method
|
Convection
|
|||||||
|
Altitude
|
Operating and
|
3,000m (10,000 feet)
|
||||||
|
Nonoperating
|
||||||||
|
Mechanical Shock
|
Random Vibration
|
0.31gRMS from 50Hz to 500Hz, 10 minutes on each axis
|
||||||
|
Nonoperating
|
2.46gRMS from 5Hz to 500Hz, 10 minutes on each axis
|
|||||||
|
Operating
|
50g, 11ms, half sine
|
|||||||
|
Mechanical
|
||||||||
|
Dimension
|
199 x 98x 40mm (L x W x H)
|
|||||||
Pls note: battery will remove from package due to shipping limit
