The JK-DR200X drilling rig with AC(Air Compressor) method is capable of drilling upto 185mm diameter holes for pore-forming purposes to a depth of 200 meters
Product Display
Product Parameters
|
Model & Name
|
JK-DR200X
|
|
Weight
|
5000 kg
|
|
Dimensions（mm）
|
3950*1700*2300mm
|
|
Power Oil
|
Diesel
|
|
Engine Model
|
QUANCHAI
|
|
Rated Power
|
65 kW
|
|
Travelling System
|
Rubber Crawler
|
|
Drilling depth
|
200m
|
|
Bore diameter
|
140-350mm
|
|
Drive Head Stroke
|
3.4m
|
|
Travelling speed
|
2.5km/h
|
|
Gradeability
|
30%
|
|
Rated pressure
|
1.7-3.0 MPa
|
|
Air consumption
|
17-30 m³/min
|
|
Drill rod diameter
|
Φ76,Φ89mm
|
|
Drill rod length
|
1.5m, 2.0m, 3.0m
|
|
Elevating capacity
|
13Ton
|
|
Swing speed
|
45-65rpm
|
|
Swing torque
|
3500-4700 N.m
|
Product Details Display
Product Advantages
1.The engine uses QUANCHAI 65 KW turbocharged engine;
2.Walking Type: crawler mounted ,trailer mounted for choice.
3.Hydraulic oil pump:Parallel gearbox design separates the oil pump unit, the power
supply is adequately distributed, the hydraulic system is uniquely designed, and the maintenance cost is small;
4.Rotary head device:gearbox integrated casting, dual motor power, large torque, durable, low maintenance costs;
5.Drilling machine chassis:professional digging chassis, durable, heavy bearing, wide chain plate, less damage to hard roads;
6.Lifting force:design composite tower, 3.4m long stroke, double cylinder lift capacity 13 ton .
supply is adequately distributed, the hydraulic system is uniquely designed, and the maintenance cost is small;
4.Rotary head device:gearbox integrated casting, dual motor power, large torque, durable, low maintenance costs;
5.Drilling machine chassis:professional digging chassis, durable, heavy bearing, wide chain plate, less damage to hard roads;
6.Lifting force:design composite tower, 3.4m long stroke, double cylinder lift capacity 13 ton .
7.Each rig is equipped with a relief valve to raise the boom to protect the cylinder and ensure work safety;
8.Each hydraulic oil pipe is covered with a protective jacket to make the oil pipe last longer.
