| Maximum turning diameter bed | 330mm |
| Maximum turning diameter of middle carriage | 210mm |
| Maximum turning diameter in the saddle | 510mm |
| Maximum processing length | 750mm |
| Width of bed | 210mm |
| Spindle speed range/Grade | 65-1600rpm/9 |
| Taper of spindle bore | MT5 |
| Chuck specifications | 160mm |
| Spindle bore | 38mm |
| Tailstock quill travel | 100mm |
| Taper of tailstock quill | MT3 |
| Cross slide travel | 200mm |
| Top slide travel | 120mm |
| Range of metric threads/Grade | 0.45-4mm/17 |
| Range of inch threads/Grade | 4.5-64mm/24 |
| Modulus thread/species | 0.45-4πmm/17 |
| Pitch thread /species | 15-192π/n”/20 |
| Motor | 2220v(380v)/2kw |
| N.W./G.W. | 660/720kg |
| Machine size | 1650×700×1300mm |
