Main Features:
1. 60W CO2 Laser Engraving + Cutting (2-in-1). Support Automatic contour cutting & Laser Engraving
2. CCD camera, scan the multiple mark points automatically to realize contour cutting function.
3. Large operation interface, all functions are iconized, even novice can operate.
4. Can be connected in a variety of ways: USB、U disk, very convenient design.
5. Cutting accuracy of +/- 0.01mm and can cut smaller fonts and letters.
Application：
Engraving or Cutting Multiple Non-metal materials,such as Vinly Film,3M Reflective Film,Paper, Stickers, Kraft Paper,Wood, Leather et.Widely used in signage, graphic arts, commercial printing, packaging, labels,promotional gifts, textiles,personalized crafts and other fields to provide excellent support and assistance.
|
Model
|
M-980LA
|
M-1380LA
|
M-1730LA
|
||
|
Max media width
|
980mm
|
1380mm
|
1730mm
|
||
|
Max cutting width
|
790mm
|
1190mm
|
1540mm
|
||
|
Packing size
|
155*50*53CM
|
195*50*53CM
|
226*54*56CM
|
||
|
Packing gross weight
|
80kg
|
96kg
|
110kg
|
||
|
Operation
|
Built-in CCD for Visible Auto contour cuttting .Touch screen LCD
（Upgraded version） |
||||
|
Motor
|
Stepper Motor
|
||||
|
Connector interface
|
COM / USB / U disk
|
||||
|
Software
|
SignMaster Software
|
||||
|
Max cutting speed |
800mm/s
|
||||
|
Power
|
50W. Optional 80W
|
||||
|
Cutting pressure
|
10-1000g （ adjustable）
|
||||
|
Repeat accuracy
|
0.0127mm
|
||||
|
Support
|
Full cut & Half cut finished simultaneously
|
||||
|
Min. character
|
Chinese character: 3mm; letter: 2mm; (varies depending on character font and media)
|
||||
|
Support material :
|
Polyester film,Kraftpaper,Cardboard,Barley paper,Release paper,Non-woven fabric,Oxford cloth,Leather,Reflective film,Post-it note, ABS board ,PVC ,Double swatch(High-ntensity reflective film),Clothing special vinyl,and some other types of
non-metallic soft materials |
||||
|
OEM/ODM
|
Welcome
|
||||
