European Quality Heavy Lathe 1325 ATC HQD Spindles Wood CNC Engraving Machine for Wooden Door

TIPTOPCNC TPR-1325 4 Cutters CNC Router comes with a high-performance configuration. And have good stability, high accuracy, low maintenance, and long service time.

Table Size

1300×2500mm

Traveling Positioning Accuracy

±0.03/300mm

X, Y, Z Repositioning Accuracy

±0.03mm

Table Surface

Vacuum and  T-slot Combined

Frame

Welded Structure

Transmission

Rack and Pinion Drive

Max. Power Consumption

(Without Spindle)  3.2Kw

Max. Rapid Travel Rate

33000mm/min

Max. Working Speed

25000mm/min

Spindle Power

3.0/4.5/6/7KW

Spindle Speed

0-18000RPM

Working Voltage

AC380V/50/60Hz,3PH (Option: 220V)

Command Language

G Code

Computer Interface

USB

Flash Memory

128M(U Disk)

Collet

ER25

X, Y Resolution

<0.03mm

Software Compatibility

Artcam Software

Running Environment  Temperature

0 – 45 Centigrade

Relative Humidity

30% – 75%

• Accuracy: Air-cooling spindle is high precision spindle, axial and radial jump are both under 0.003mm.
• Heat dissipation: air-cooling spindle works well on using water circulation to cool the heat generated by high speed rotating of the spindle, through water flow the temperature won’t exceed 40 degrees.
• Noise: The air-cooling spindle is quiet compared with the water cooling spindle.

2. Control system: Taiwan LNC. (Mainly used on auto tool changer)

• The machine parameters are set up before delivery, don’t need the second set
• Do not require to connect the computer, The system comes with a touch screen
• Easy to operate and learn, Professional operation manual is included

3. Transmission: Gear transmission, which ensures high speed.

• High-quality Taiwan Hiwin Square rail 30mm ensures high working precision.

4. Control box

• The well organized control box with labeled wires.

• Greatly save time for holding materials

• which is for regularly lubricate guide rails, save time on maintenance

7. T Slot and Vacuum Table

• Easy to fix, saves fixed time and improves efficiency

1.The Advertising industry:
TIPTOPCNC developed several comprehensive CNC machining solutions and important productivity options for signmakers. The flexibility of a TIPTOP CNC router allows commercial sign fabricators to produce dimensional signage engrave all kinds of signage, trademark, nameplates, badge, decorative gifts, embossed medal, certificate, souvenir, photo frame, furniture decoration. Additional productivity options include misters for wood, PVC, MDF, aluminum, aluminum composite panel, and other non-ferrous metals.

2.Small-scale woodworking industry:
Making a cabinetmaker’s job easy. Our CNC routers have made the manufacturing of all kinds of doors(solid wood door, composite door), solid wood furniture, mahogany furniture, MDF paint door, cupboard door and window, bedside cabinet, folding screen etc. countertops, shelves, drawers and drawer fronts available to small, mid-size and large businesses alike. Operating a CNC machine allows cabinetmakers to use a manufacturing technique that improves production time, quality and consistency, as well as material yield, all utilizing a single machine and the right software system. Cabinetmaking involves all types of wood (both natural and processed), and sometimes some plastics as well.

3.Artwork industry
CNC router can process wooden craft, mural art of wood, embossed, jewelry, cosmetics package, musical instrument.

1. Return On Your Investment

The components of our CNC machines are sourced from various parts of the world to give you the best value offer without compromising on quality.

2. Quality Control

Before the machine arrives at your facility, we have performed a detailed and thorough quality control process. Each machine is tested to ensure you have no operational issues from day one.

3. Increased Productivity

The UnionTech CNC product line will reduce your waste, reduce costly errors and increase productivity. You will be able to cut down on the number of machines in your shop.

4. Dedicated Support

We are committed to your success. Our technician team of CNC experts are available through a phone or computer to help you get in contact with your CNC machine.

5. We Are With You All The Way

We will walk you through every step, from purchase to production, we help you with selecting the right software for your application, training, and setup. And we will not sell you a machine unless we make sure it can do the job. If you send us a sample material, we will test it on the machine you would like to buy and send the piece back to you.

Packaging Details: Three Layers

1. Transparent waterproof plastic wrap

2. Shockproof form

3. Plywood Craft Case

*The machine can be packed according to your requirements.

The machine will be shipped out 10-15 days after receiving the first payment.
