Electromagnetic Digital Water Flow And Pressure Meter Liquid Urea Flow Meter

ر.س2,110.96

Clear
Qty:
Compare

Request quotation for: Electromagnetic Digital Water Flow And Pressure Meter Liquid Urea Flow Meter

electromagnetic digital water flow and pressure meter liquid urea flow meter

Product Description

Electromagnetic flow meter  adopts Chinese and English display smart converter with 16-bit embedded microprocessor. All digital processing, with two-way flow measurement function, instantaneous flow and positive and negative direction of the cumulative amount and the cumulative amount. Used to measure the volume flow of conductive media such as clear water, sewage, acid, alkali, slurry, food grade liquid, salt solution  liquid.

 magnetic water flowmeter29.JPG

Parameters


Dimension

magnetic water flowmeter31.JPG

electromagnetic digital water flow and pressure meter liquid urea flow meter



magnetic water flowmeter3.jpg


QQ20190423130115

Order sheet

Name

Specification code

Explanation

Instrument type



electromagnetic digital water flow and pressure meter liquid urea flow meter

Diameter code

AT-xxx

For example:100 represents DN100

Electrode form

1

Standard stationary type









Electrode material

0

Stainless steel(316L)

1

Platinum Pt

2

Hastelloy B(HB)

3

Tantalum Ta

4

Titanium Ti

5

Hastelloy C(HC)







Lining material

3

Chloroprene rubber

4

Polyurethane rubber

5

F4(PTFE) polytetrafluoroethylene

6

F46(FEP)polyperfluoroethylene-propylene







Rated pressure(MPa)

1.6

DN10-80

1.6

DN100-150

1.0

DN200-1000

0.6

DN1100-2000

0.25

DN2200



Operating temperature

E

<80℃

H

<120℃

Grounding



Built-in grounding electrode

Grade of  protection

0

IP65

1

IP68

Converter type

0

Integral type

1

Split type

Case material

0

Carbon steel

1

Stainless steel

Instrument flange

0

Carbon steel

1

Stainless steel

Installing timing flange

0

Without

1

With

Power supply source

0

220VAC

1

24VDC



   Application

acid flow meter14.JPG

 water flow meter.jpeg

Package

magnetic water flowmeter12.JPG




 Other types of flow meter: ultrasonic water flow meter/ vortex flow meter, please click the following pictures!

paste-pic-dp_uuid_kjbmkvortex gas flow meter33

                      Welcome inquiries!!!

Accuracy

0.5

Material

stainless steel
