Product Description
Brand name: DFY Place of origin: Henan, China Power:Electric Standard or Nonstandard: Standard Model number: HB3 Pressure: High Pressure
OEM: Accept Dimension:1033*474*940mm
Total weight: 250kg Working pressure: 1.5Mpa
Motor power: 4kw Name: Cement grout pump
Delivery height: 40m Certificate: CE,ISO9001:2008
Structure: Piston pump Application: Grouting equipment
Times of Two-way Movement of Piston: 150times/min
| Thechnical Paraments of Concrete Pump HB-3 | ||
| Specification | HB3 | 2HB6 |
| Delivery Capability | 3m³/h | single 3m³/h Double |
| Delivery Height | 40m | 40m |
| Horizental Delivery | 150m | 150m |
| Working Pressure | 1.5Mpa | 1.5Mpa |
| Motor Power | 4kw | 5.5kw |
| Motor Rotating | 1440r/min | 1440r/min |
| Motor Outlet Pipe | 51mm(2”) | 51mm(2”) |
| Motor Inlet Pipe | 64mm(2.5”) | 64(2.5”) |
| Weight | 250kg | 320kg |
| Over Size | 1035*480*900 | 1614*530*1110 |
