Eco-Friendly mini rotary drum dryer

mini rotary drum dryer is one of traditional dryer machines. chicken manure drum dryer has such advantages as reliable working condition,elastic operation, strong adaptability and high processing capacity, so that it is widely used inmany fields such as metallurgy, building material, chemistry, coal washing, fertilizer, sand, ore, clay, kaolinand sugar.

The diameter of mini rotary drum dryer is 1000-4000mm, and the length can be determined according to

the specific drying requirement. The moist materials that go inside the cylinder of the mini rotary drum dryer machine will be repeatedly lifted and scattered by the lifting board on the rotating wall, and in the falling process, the materials will be crushed by the scattering device into fine particles whose specific area is greatly

increased, and the fine materials will sufficiently contact the hot air and will be dried.

 Features of mini rotary drum dryer

1. mini rotary drum dryer is widely used in such industries as fodder, chemistry, medicine and mine.
2.The working process of mini rotary drum dryer goes like this: the moist materials whose water has been drained go into the dryer machine, under the rotation of the lifting board evenly installed inside the roller

drum, the materials will be evenly scattered inside the drying machine and carry out sufficient contact with

the hot air, thus accelerating the heat transfer and mass transfer.
3.In the drying process, under the lifting board with a certain inclination and the heat media, the materials

will move to the lower end of chicken manure drum dryer and be discharged.
4. mini rotary drum dryer is suitable for drying residue materials whose water content is below 85% such

as brewer’s grain, bean dregs, guniting corn bran, slurry and pomace, so that it has excellent effect for opening up fodder resources, reducing the feeding cost and reduce environment pollution.

Componets of mini rotary drum dryer

mini rotary drum dryer is mainly consisted of :

1) Furnace

2) Connection pipes between chicken manure drum dryer and furnace

3) Feeding Device

4) rotary drum dryer roller ring

5) Big gear(45# steel)

6) Transmission parts ( Motor, Reducer, Bearing, Small gear)

7) Carrier Roller of chicken manure drum dryer

8) Discharing Device

9) Cyclone

10) Dust Remover

11) Air induced fan

 We can supply whole set fertilizer production line,we can design the whole plant line according to your need and your factory size.
