Easy to operate prestressed Mixer Pump Machine Mortar Pumping concrete pump
HB Series Mortar Pump has the advantages of simple structure, flexible operation, convenient maintenance, high lift, small pulse, high pressure, large pump and good grouting effect. It is mainly used in high-rise buildings, highways, railway bridges, subway tunnels, water conservancy dams and other large projects. It is an ideal prestressed tunnel grouting, mortar conveying and spraying construction machinery.
|
Specification |
HB3 |
2HB6 |
|
Delivery Capability |
3m³/h |
single 3m³/h Double |
|
Delivery Height |
40m |
40m |
|
Horizontal Delivery |
150m |
150m |
|
Working Pressure |
1.5Mpa |
1.5Mpa |
|
Motor Power |
4kw |
5.5kw |
|
Motor Rotating |
1440r/min |
1440r/min |
|
Motor Outlet Pipe |
51mm (2”) |
51mm (2”) |
|
Motor Inlet Pipe |
64mm (2.5”) |
64mm (2.5”) |
|
Weight |
250kg |
320kg |
|
Over Size |
1035*480*900 |
1614*530*1110 |
It is mainly used in high-rise buildings, expressways, railway Bridges, subway tunnels, water DAMS and other large-scale projects.It is an ideal construction machine for grouting, mortar conveying and spraying of prestressed orifice.
The equipment has the advantages of simple structure, flexible operation, convenient maintenance, high head, small pulse, high bearing pressure, large pump and good spraying and grouting effect.
