Digital Viscometer 8S, Digital Display Viscometer, Paint Viscometer

Compare

Request quotation for: Digital Viscometer 8S, Digital Display Viscometer, Paint Viscometer

Digital Viscometer 8S, Digital Display Viscometer, Paint Viscometer

DJ series digital viscometer is the instrument that has been adopt the most advanced newest mirco-computer drive technology,imported stepping motor,and LCD displaying.It has the function of stable rotate speed,high accuracy,easy operation,error alarm and automatic scanning;It can provide the best combination for rotor and rotate speed;Automatically displaying the maximum measuring range for the combination chosen;Screen can directly display the following data:viscosity,rotate speed,percentage torque,rotor model and temperature for the testing objects.

DJ series digital viscometer can measure the absolute viscosity for newtonian liquids and apparent viscosity for non-newtonian liquids.If choose viscometer data processing software,can analyze the simple rheological property for non-newtonian liquids.

Application:
Grease,paint,coating,sizing agent,spinning,food,medicine,cementing compound,cosmetic.,etc.

Features:

Displaying measuring data directly.no need to do the manual calculation.
Adopt the advanced newest micro-computer drive technology and imported stepping motor.It has the stable rotate speed.
Adopt the advanced power source technology.the variation of power frequency will be no effection on the measuring accuracy.
Integration design,easy operation,convenient and reliable.
Function of automatic scanning.provide the best combination for rotor and rotate speed.make sure accurate testing result.
Automatically displaying the maximum measuring range for the combination chosen of rotor and rotate speed.
Can equip the adaptor (“0” rotor).of which for measuring lowest viscosity.to measure the viscosity at 1-100mpa.s.
Can choose the temperature probe,real-time measure the temperature of testing objects.
Has the interface of RS-232 or the USD2.0,can output data.and connect external device.
Can choose the data processing software.

Technical Specification:

Model	DH-DJ-5S	DH-DJ-9S	DH-DJ-8S
Displaying	Back light Displaying in English
Automatic Scanning Function	Automatically recommend the best combination for rotor and rotate speed.easy operation,accurate testing result
Automatic Range Displaying	Automatically displaying the measurable maximum range for the combination of rotor and rotate speed
Rotate Speed(r/min)	6/12/30/60		0.3/0.6/1.5/3/6/12/30/60
Rotor	Standard package 1,2,3,4 (Can choose 0# rotor to measure the lowest viscosity less than 10)
Measuring Range(mPa.s)	1.0-100,000		1.0~2,000,000
Measuring Error(Newtonian liquid)	±1%	±0.5%	±1%
Repetitive Error(Newtonian liquid)	±0.5%	±0.25%	±0.5%
Temperature Measuring	yes
Constant Temperature Parts	Optional Accessory
Data Output Interface	Yes
Data Processing Software	Optional Accessory	Optional Accessory	Optional Accessory
Overall Dimension	300 × 300 × 450(mm)

FAQ

1.Quality Insurance

We guarantee this instrument for 12 months and life-long maintenance

We will be responsible for fixing or replacing the instrument if quality issue was arisen,the service is excluding if the machine is breakdown caused by following reasons:

(1) Wrong operation;

(2) Fixed or refitted personally;

(3) The machine itself is not the reason caused breakdown;

(4)Applying the machine under the serious conditions.such as high

temperature,moist, corrosive gas,or vibration.

(5)Move or transportation as soon as installed.

(6)Consumables and easy-loss components.

(7)Natural disaster

2.After-sales Service

a.If errors occur,please refer to the troubleshooting tips of the instruction manual.

b.Please contact with our after-sales service department or distribute in time if can’t clear fault.

c.DahoMeter after-sales hot line 400 830 0646

3.Shipping

Air shippment

International Express:DHL/UPS/FEDEX/TNT

4.Are we manufacturer made copy product or original product?

We are the original manufacturer for densimeter,DahoMeter is our own brand.the model starts with DH is belongs to us generally.

5.Why choose us

We deep understood what’s you need is not only product,but also all-around service support,especially for technical instruction and after-sales service.

a.We have been specialized in density field for almost 13 years.

b.Professional researching and technology team.

c.Customer service team.
