| Model | DRK1325 |
|
X,Y Working Area |
1300*2500mm |
|
Laser power |
60w 80w 100w 120w 130w 150w 180w |
|
Laser type |
CO2 |
|
Laser head NO. |
One ( two heads option) |
|
Reflector and focus mirrors |
Imported |
|
Linear rail |
High quality Taiwan PMI square rail |
|
Table type |
One Knife table and one Honeycomb table
|
|
Cooling system |
CW3000/CW5200 Water chiller |
|
Other accessories |
Exhaust fan,Air compressor,red dot etc all necessary |
|
Engraving Speed
|
0-60000mm/min |
|
Cutting speed |
0-36000mm/min |
| Resetting position accuracy | ±0. 01mm |
| Control system | RD6445G control system with WIFI wireless control |
| Software | RDworks V8 |
| Graphic format supported | BMP, PLT, DST, DXF, AI, JPG, GIF, PGN, TIF |
| Software supported | CorelDraw, PhotoShop, AutoCAD, TAJIMA,Artcut |
|
Laser Output |
1-100% Software Setting |
| Operating temperature | 0 – 45℃ |
| Operating humidity | 5 – 95% |
| Working Mode | 3-phase Stepper motor |
| Dichroic Cutting | Up to 256 colors |
|
Gross power |
<2200W |
| Minimum shaping character | English 1 x 1mm |
| Working Voltage | 220V/50HZ -60HZ; single phase ( 110v option) |
1.Within 7 days since your local customs clearance: if the machine’s any parts has any problems,we will change it free.
2. Exceed 7 days since your local customs clearance but within warranty period: if the machine parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.
3. Exceed warranty period: if the machine parts have any problems,we can offer new machine parts with cost price and you also should pay all the shipping cost.
4.We offer 24 hours technical support by call, email.
5.Our technician can give you remote guide online(Skype/MSN/What’s app/viber/Tel/Etc) if you have any question.
6.We can record videos of operating the machine.
