Product Description
Major functions:
1. Double function of rebar and rust test. 2. Identify rebar location, direction and distribution. 3. Test the thickness of concrete cover. 4. Test rebar diameter. 5. Qualify the thickness of concrete cover automatically. 6. Single-electrode testing of concrete rebar corrosion. 7. Double-electrode testing of concrete rebar corrosion. 8. Divide rebar corrosion in maximal 10 gray shades or color graphs. 9. Test data storage, check and transmission. 10. Analyze professionally with Test Data Processing Software.
Major characteristics
1. Store data in U-disk. 2. While GPRS module is equipped on the detector, the data can be transmitted with GPRS, which is convenient and fast. 3. Place brief introduction of functions and operation manual inside, handy for check. 4. Draw contour map of corrosion potential 5. Soft backlight.
ZBL-R630A tests the thickness of concrete cover, rebar diameter, location and space.
|
Measurement range of cover
(rebar diameter Φ6mm-Φ50mm)
|
First range: 3mm～98mm
Second range:3mm～196mm
|
|
Detection range of corrosion voltage
|
-1000mv～+1000mv
|
|
Detection precision of corrosion voltage
|
0.1mv
|
|
Power supply mode
|
lithium battery Inside (charge with standard configured charger)
|
|
Working time
|
38 hours
|
|
Weight
|
0.9kg
|
|
Volume
|
212mm×134mm×50mm
|
|
Display
|
160*128, LCD
|
|
USB port
|
Transmit with U-disk, with capacity
|
